RWK/RWF/RWG

Your Heating Specialist since 1949

Resistance Wire
Product Highlights
Same Multi-Stranded Wire We Use In Our High Quality Heating Element
Provides Greater Flexibility and Durability Than Solid Strand Wires
CABLE / WIRE

Flexible up to a 1/16” (1.6mm) Radius
500ft (152m) or 1000ft (305m) Standard Spools Sizes
RWK Polyimide Film Insulated Resistance Wire:
Specifications:
• Insulation type: 1 mil polyimide film with 50%
overlap
• Insulation thickness: 2 mil
• Dielectric strength: Over 2000 volts
• Suitable for use on conductive surfaces
•
rated to 482°F (250°C), 600VAC, AWM 5417

RWK

•

RWF Fiberglass Insulated Resistance Wire:
Specifications:

• 1100°F (593°C) maximum continuous exposure
temperature
• Ιnsulation type: Two layers of 8 mil diameter
strands of fiberglass yarn
• Dielectric strength: Over 2000 volts
• Νot suitable for conductive surfaces
• Optional PTFE coating provides
anti-fraying and abrasion resistance
•

RWF

RWG Grounded Resistance Wire:
Specifications:

• Patented grounded braid through entire length

of heating element
• Insulation type: 1 mil polyimide film with 50%
overlap
• Insulation thickness: 2 mil
• Two layers of 8-mil diameter fiberglass braided

over polyimide film
• Dielectric strength: Over 2000 volts
• Suitable for use on conductive surfaces
• Optional PTFE coating provides anti-fraying and abrasion
resistance
•
rated to 482°F (250°C), 600VAC, AWM 5418

RWG

•
