Heating Cable Accessories
Your Heating Specialist since 1949
CABLE / WIRE
Adhesive Tape
Helps to isolate the cable from the insulation and provides intimate contact with surface to be heated.
Part Number Description
PSAT36A Fiberglass Adhesive Tape: Size: 0.5” x 108’( 13mm x 38m) Temp Limit: 350 ° F( 176 ° C)
AAT260 Aluminum Adhesive Tape: Size: 2” x 180’( 51mm x 55m) Temp Limit: 350 ° F( 176 ° C)
AAT2180 Aluminum Adhesive Tape: Size: 2” x 180’( 51mm x 55m) Temp Limit: 550 ° F( 288 ° C)
Junction Box
Metallic Junction Box with watertight cover. Suitable for use in ordinary and wet locations. NEMA 3R rated with gasket and cover.
File No. 195978
File No. C22.2 No. 18 Part Number JBM050
JBM075
JBM100
Description
Metallic Box 3 hub 1 / 2” NPT Dimensions: 2” x 4-1 / 2” x 2-3 / 4”( 51mm x 114mm x 70mm)
Metallic Box 3 hub 3 / 4” NPT Dimensions: 2” x 4-1 / 2” x 2-3 / 4”( 51mm x 114mm x 70mm)
Metallic Box 3 hub 1” NPT Dimensions: 2-5 / 8” x 4-1 / 2” x 2-3 / 4”( 67mm x 114mm x 70mm)
Hazardous-Area Rated Junction Box available upon request.
Heat Conductive Putty
Used to fill voids between cable and pipe surface.
Part Number |
Description |
HCP1 |
Size: 1 lb.( 0.5kg) |
HCP3 |
Size: 3 lb.( 1.4kg) |
Electrical Tracing Caution Label
Recommended for every 10ft( 3m) of heat trace.
Part Number |
Description |
BCLCAB |
Caution label( English) |
BCLCAB-DE |
Caution label( Deutsch) |
BCLCAB-ES |
Caution label( Espanol) |
BCLCAB-FR |
Caution label( Frances) |
BCLCAB-IT |
Caution label( Italiano) |
Pipe Standoff
Aluminum standoff for mounting junction boxes to pipe.
Part Number PSOCAB075 PSOCAB010
Description 3 / 4” NPT thread 1” NPT thread
Pipe Strap
Stainless steel pipe straps used to secure pipe standoff to pipe.
Part Number
Description
BPSCAB2-6 Adjustable from: 2” to 6”( 51mm to 152mm)
RTV Sealant
Silicone sealant used to seal lead pouches, end pouches, and pipe standoffs.
Part Number
Description RTV3.0 3 oz.( 89ml)
Monitor Light Kit for BriskHeat ® Constant Wattage Heating Cable
Provides an end of circuit continuity indication for all types of constant wattage heating cable. For use in ordinary locations.
Part Number MLK1001 MLK2001 MLK1002 MLK2002 MLBCAB001
Description Single hub; 120VAC Single hub; 240VAC Double hub; 120VAC Double hub; 240VAC 120VAC replacement bulb 40180 240VAC replacement bulb
INSUL-LOCK ® DS Insulation
Flexible thermal insulation for pipes and tubing. Adhesive flap closure.
Part Number
Recommended Pipe / Tube O. D.
Insulation I. D.
INSUL78 |
1 / 2”- 5 / 8” |
7 / 8” |
INSUL118 |
3 / 4”- 7 / 8” |
1-1 / 8” |
INSUL138 |
1” |
1-3 / 8” |
INSUL158 |
1-1 / 8” |
1-5 / 8” |
INSUL2 |
1-3 / 8” |
2” |
INSUL218 |
1-5 / 8” |
2-1 / 8” |
INSUL238 |
2” |
2-3 / 8” |
INSUL258 |
2-1 / 8” |
2-5 / 8” |
INSUL278 |
2-3 / 8” |
2-7 / 8” |
INSUL318 |
2-5 / 8” |
3-1 / 8” |
INSUL312 |
2-7 / 8” |
3-1 / 2” |
INSUL358 |
3-1 / 8” |
3-5 / 8” |
INSUL418 |
3-1 / 2” |
4-1 / 8” |
INSUL412 |
4” |
4-1 / 2” |
22
