KK High Temperature Constant-Wattage Heating Cable
Product Highlights
Temperatures up to 500 ° F( 260 ° C)
Power remains constant regardless of temperature
Can be cut-to-length at job site
Ideal for a wide range of high temperature applications:
• Viscosity control
• Asphalt lines
• Heavy oil lines
• Nuclear environments
• Locations where halogens are not permitted
• Process lines subject to high pressure steam blow down
Specifications:
• Maximum exposure temperature 500 ° F( 260 ° C)
• Moisture, chemical, flame, and radiation resistant
• 12AWG bus wires
• Dimensions 0.2” x 0.3”( 5mm x 8mm)
• 30 lb.( 14Kg) per 500-foot( 152m) spool
Approvals:
FM APPROVED
Ordinary Locations Hazardous Locations: Class I, Division 2, Groups B, C, & D Class II, Division 2, Groups F, & G Class III, Division 2
Approvals valid only when used with appropriate heating cable and installation accessories, and installed in accordance with all applicable instructions, codes, and regulations.
Ordering Information:
Part Number Matrix: KKCAB 8 120
Cable Type 120VAC 208VAC 240VAC 277VAC 480VAC
4 watts / ft( 13 watts / m)
8 watts / ft( 26 watts / m)
12 watts / ft( 39 watts / m)
18 watts / ft( 59 watts / m)
Your Heating Specialist since 1949
Heating Element
Contact Module Point
Tinned Copper Overbraid
Maximum Circuit Length in ft( m)
310( 94)
220( 67)
180( 55)
120( 37)
537( 164)
381( 116)
312( 95)
208( 63)
Bus Wires
Heat Fused Polyimide Film
Heat Fused Polyimide Film
620( 189)
440( 134)
360( 110)
240( 73)
716( 218)
508( 155)
416( 127)
277( 84)
1240( 378)
880( 268)
720( 220)
480( 146)
Watts / ft: 4, 8, 12, 18
Voltage: 120, 208, 240, 277, 480
Cable Type 120VAC 208VAC 240VAC 277VAC 480VAC
4 watts / ft( 13 watts / m)
Circuit Module Length in ft( m)
4.0( 1.2)
4.0( 1.2)
4.0( 1.2)
4.0( 1.2)
8.0( 2.4)
8 watts / ft( 26 watts / m) |
2.0( 0.6) |
4.0( 1.2) |
4.0( 1.2) |
4.0( 1.2) |
6.0( 1.8) |
12 watts / ft( 39 watts / m) |
2.0( 0.6) |
4.0( 1.2) |
4.0( 1.2) |
4.0( 1.2) |
7.0( 2.1) |
18 watts / ft( 59 watts / m) |
|
|
|
|
|
1.75( 0.5) |
|
|
|
|
3.0( 0.9) |
3.5( 1.1) |
4.0( 1.2) |
5.5( 1.7) |
When ordering, please allow a minimum of 1 module length extra for terminations.
See page 21 & 22 for connection / termination kits and accessories.
IMPORTANT: Temperature controller is required for this product. See pages 86 though 104 for options.
