14th-Edition-BriskHeat-Product-Catalog A | Page 30

KE

Your Heating Specialist since 1949

KE Harsh Environment Constant-Wattage Heating Cable
Product Highlights

Bus Wires

Temperatures up to 500°F (260°C)
Power remains constant regardless of
temperature

Heating Element
PFA Extruded
Jacket

Can be cut-to-length at job site
Contact Module
Point

CABLE / WIRE

Ideal for a wide range of applications in
corrosive environments:
• Freeze protection
• Viscosity control
• High temperature process control
• Asphalt plants
• Oil refineries
• Mines
• Chemical and petrochemical
processing areas
• Other explosive and corrosive
atmospheres
• Severe arctic cold

Heat Fused
Polyimide Film

Tinned Copper
Overbraid

Specifications:

• Maximum exposure temperature is 500°F
(260°C)
• Moisture, chemical, flame, and radiation
resistant
• 12AWG bus wires
• Dimensions 0.2” x 0.3” (5mm x 8 mm)
• 41lb. (19kg.) per 500-foot (152m)

Continuous
Marker Tape

PFA Extruded
Jacket

Approvals:

FM

APPROVED

Ordinary Locations
Hazardous Locations:
Class I, Division 2, Groups B, C, & D
Class II, Division 2, Groups F, & G
Class III, Division 2

Maximum Circuit Length in ft (m)

Approvals valid only when used with appropriate heating
cable and installation accessories, and installed in
accordance with all applicable instructions, codes, and
regulations.

Ordering Information:
Part Number Matrix

KECAB 4 120

Cable Type

120VAC

208VAC

240VAC

277VAC

480VAC

4 watts/ ft
(13 watts/ m)

310
(95)

537
(164)

620
(189)

716
(218)

1240
(378)

8 watts/ ft
(26 watts/ m)

220
(67)

381
(116)

440
(134)

508
(155)

880
(268)

12 watts/ ft
(39 watts/ m)

180
(55)

312
(95)

360
(110)

416
(127)

720
(220)

Circuit Module Length in ft (m)

Watts / ft:
4, 8, 12
Voltage:
120, 208, 240, 277, 480

Cable Type

120VAC

208VAC

240VAC

277VAC

480VAC

4 watts/ ft
(13 watts/ m)

4.0
(1.2)

4.0
(1.2)

4.0
(1.2)

4.0
(1.2)

8.0
(2.4)

8 watts/ ft
(26 watts/ m)

4.0
(1.2)

4.0
(1.2)

4.0
(1.2)

4.0
(1.2)

6.0
(1.8)

12 watts/ ft
(39 watts/ m)

2.0
(0.6)

6.0
(1.8)

4.0
(1.2)

4.0
(1.2)

6.0
(1.8)

When ordering, please allow a minimum of 1 module length extra for terminations.

See page 21 & 22 for connection/termination kits and accessories.

IMPORTANT: Temperature controller is required for this product. See pages 86 through 104 for options.
