TT
Your Heating Specialist since 1949
TT Table Top Composite Curing Controller
Product Highlights
Provides basic temperature control for
composite curing applications
Portable, lightweight, and self-contained
Eight-segment ramp / soak control
Universal voltage option and high amperage
capability: up to 30 amps
Specifications:
400ºF (204ºC) maximum temperature control
Simple four-key user control
Dual display shows set-point and actual temperature
14 programmable alarm types
Programmable to either ºC or ºF
Visual and audible alarms
Automatic tuning of PID parameters
Accuracy ±1 least significant digit
Ιnput Voltage:
- Universal voltage model: 100-130VAC, 200-240VAC, 50-60Hz
- 120V model: 100-130VAC, 50-60Hz
30 amp circuit breaker
Αccepts standard and mini Type-J thermocouple connectors
Sensor break protection
Auto / manual control ability
Program security lock levels
6-foot (1.8m) long input power cord
Add Vacuum Capabilities
with Optional Venturi Pump
Ordering Information:
TT Table Top Controller Kit
Part Number
Description
TT30D-S16
TT Table Top Temperature Controller Kit, Universal voltage
TTQSD-S16
TT Table Top Temperature Controller Kit with built-in high limit
thermocouple input, 120VAC
C O M P O S I T E
CURING
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
TT Table Top Controller Kit includes...
- One TT Table Top Controller unit
- One 20ft Type J Thermocouple (TTQSD-S16 includes two)
- One 10ft Heater Output Cord
Deluxe Packages
Accessories
Part Number
Description
Part Number
Description
TT30D-S16-120KIT
TT30D-S16 with 120V Heating Blankets
- One 10” x 10” (254mm x 254mm) SR heating blanket
- One 12” x 12” (305mm x 305mm) SR heating blanket
20950
Venturi pump. Converts shop
/ compressed air to vacuum.
Requires shop / compressed air.
TT30D-S16-240KIT
TT30D-S16 with 240V Heating Blankets
- One 10” x 10” (254mm x 254mm) SR heating blanket
- One 12” x 12” (305mm x 305mm) SR heating blanket
49758-35
Vacuum gage
20938
10ft (3m) vacuum hose
20931
Vacuum bag feed-through
49909-01
20ft (6m) Type J Thermocouple
TT30D-S16-VACKIT
TT30D-S16 with Vacuum Kit
- One Venturi pump
- One 10ft (3m) vac uum hose
- One vacuum feed-through
