SDC
Your Heating Specialist since 1949
SDC Digital On/Off Benchtop Temperature Controller
Product Highlights
Affordable and compact
Compatible with a wide range of heaters and
applications
Easy-to-use programmable digital controller,
self contained, plug and play design
Heater Sold Separately
Includes thermocouple and power output cords
Specifications:
•
•
•
•
•
•
•
•
•
•
Size:
- Length: 5.5” (140mm)
- Width: 4.25” (108mm)
- Height: 1.75” (45mm)
On-Off control
Temperature control range:
- °F models: 32°F to 999°F - Accuracy: +/- 1% FS
- °C models: 0°C to 700°C - Accuracy: +/- 1% FS
Includes 5-foot (1.5 m) factory installed J-type or K-type
thermocouple sensor
120 VAC or 240 VAC power input
Relay output rated for 10A @ 120/240 VAC
Sensor break options
Upper and lower limits of the setpoint can be adjusted
Hysteresis: Adjustable setting from 1° to 99° (F or C)
Exposure temperature: 32°F to158°F (0°C to 70°C)
- 80% humidity non-condensing
5-foot (1.5 m) input power cord
- 120VAC unit = NEMA 5-15 plug
- 240VAC unit = NEMA 6-15 plug
5-foot (1.5 m) output power cord
- 120VAC unit = NEMA 5-15R receptacle
- 240VAC unit = NEMA 6-15R receptacle*
Internal buzzer for alarm condition/error
CONTROLLERS
•
•
•
Note: Other plug receptacle options available. Contact us for more information.
Ordering Information:
Part Number
Voltage
Degrees C or F
Thermocouple Type
SDC120JF-A
98-132VAC
°F
J-Type
SDC120KF-A
98-132VAC
°F
K-Type
SDC120JC-A
98-132VAC
°C
J-Type
SDC120KC-A
98-132VAC
°C
K-Type
SDC240JF-A
184-253VAC
°F
J-Type
SDC240KF-A
184-253VAC
°F
K-Type
SDC240JC-A
184-253VAC
°C
J-Type
SDC240KC-A
184-253VAC
°C
K-Type
* Plug Option: Add an “E” at the end of the part number for input power
leads with ferrule wire crimped termination. i.e. SDC240JC-AE
Provided with loose NEMA 6-15 plug.
Toll Free: 800-848-7673
Phone: 614-294-3376
w w w .BriskHeat. c o m
Email: bhtsales1@briskheat.com Fax: 614-294-3807
© BriskHeat Corporation. All Rights Reserved. 16-03
