#5 Spline Drive Impact Sockets
& Attachments
MADE IN USA
#5 Spline Drive Impact Sockets
Part No. Description
5800 #5 Spline Impact Universal
Meets or exceeds ASME B107.110
#5 Spline Impact Adaptor
Part No. Nom. Size L
5901 #5F x 1“M” 3-21/32"
Ds
–
Dd Bd
2-3/8" –
Guarantee does not apply
Meets or exceeds ASME B107.110
S HAP E l SHAPE ll
S HAP E l I l SHAPE lV
Always use a Ret Ring ® when
working with impact products.
www.wrighttool.com
#5
Spline
Wright Tool spline drive sockets and adaptors are manufactured from
4140 alloy steel and heat treated for maximum strength. Openings are
hot forged to close tolerances and the 14 tooth female spline is designed
for a snug fit. It also has an internal groove that fits the locking devices
on all #5 Spline Drive Impact Wrenches.
235
