PEDALBOARDS
ANDY RAHARJO
As I mentioned during the NAMM , I mainly don ’ t play thru pedalboard instead I play direct thru rack systems .
Either thru the rack system or play thru Axe FX Fractal FM9 using the direct method .
This is the rack diagram for the Worship Night rig , depending on the service set list and the needs .
The system architecture is intended to do it all from swells too big droning types of sound . I have a common patch in FM9 and it sounds sterile . The rack system is way more color- in a good way and definitely can be used both in the studio and live situations .
Now , transportation could be a challenge . However , I always believe that He will provide so I have an amazing worship service team that helps me to transport the rig . I also get smarter by dividing the rack into three separate cases and labeling the connections . Below is a quick snapshot of how it is evolving into a more modular rack system .
I forgot to mention . Samson SM10B line mixer .
All the chain output from Loop 6 thru 10 are going to mixer IN . Mixer L / R out goes back to HUSH L / R . Chorus is daisy chained after that which is going to be L11 left and L11 right .
The system out front panel will be patched back to my patch panel and go to Fryette
So it ’ ll be dry / wet setup . If I need to do wet / dry / wet then I ’ ll split the connection in loop 3 out and goes to any EL34 power amp ( bogner , Marshall , peavey or whatever available )
WDW will need three cabinets with vintage 30 on the sides and dry would use EVM12L or something like celestion copper back .
I will control the mix and listen the tone thru Alclair Studio 3 IEM .
For church live setup , w / d / w output from RSB Bradshaw will go to three two notes cab M plus pedal . I will ditch all the cabinets and power amps or any amplifier since the setup will go direct to the house .
With the James Tyler Huff Classic Black electric guitar , I can facilitate any kind of Praise and Worship songs . Eventide eclipse mostly provides the ambiance and swell airy patch . Poly effects Beebo also does heavy work in capturing long tail reverb or even layer the shimmer .
# WMPEDALBOARD
