What is lift and slide?
G-ULift and
Slide door
systems
Create
unobstructed
views with easy
opening and
closing.
Lift and slide doors are unlike your average sliding door.
Lift and slide door systems separate the sliding and sealing/locking actions
from each other. Lift and Slide allows the door panels to be lifted above
the track and seals to slide (roll) easily when opening or closing the door.
This easy operation of even large and heavy panels is the result of the
perfect interplay of running carriages, gear and lever handle. This is
different to the current conventional sliding doors in the Australian market
that drag across the seal causing friction and noise.
Key features:
• Panel sizes up to 2.8 m high and 3.3 m wide
• Maximum panel weights up to 400 kg (300 kg is standard)
• Up to six panels per opening, allowing an 18 m opening
• Extremely smooth and quiet rolling operation
• Optimum corrosion protection with ferGUard*silver
Product benefits:
• Doors can be built to the size of an entire wall making them the
ideal choice for maximizing the view and bringing the outside in
• Wider door panels reduce the size of the mullions giving a less
unobstructed view
Product options:
This product is just one of the many unique
products that the Lincoln Sentry Window Door
& Glazing Division has in our Performance
Hardware portfolio. For more information please
contact your nearest Lincoln Sentry branch on
1300 551 919.
• Automatic and fully concealed versions (HS-Master) available
• An integrated slit ventilation system (optional) allows air flow whilst
maintaining security
• Speed limiter is also available to control speed and limit the potential
for personal injury and damage to the door itself
