Patch Panel

Patch Panel
Telecom.

TELCO Patch Panel
10 BASE-T Wiring Patch Panel

A

B

Part No.

Port

3012IP-TC128-BK

1U12

Cat.3 TELCO 10 BASE-T wiring pat ch panel, modular jack to 1 female TELCO connector

A

3012IP-TC248-BK

1U24

Cat.3 TELCO 10 BASE-T wiring pat ch panel, modular jack to 2 female TELCO connector

B

3012IP-TC488-BK

2U48

Cat.3 TELCO 10 BASE-T wiring pat ch panel, modular jack to 4 female TELCO connector

100 BASE-T Wiring Patch Panel

A

B

Part No.

Port

3012IP-TCN248W-C5BBK

1U24

Cat.5 TELCO 100 BASE-T T568 B wiring patch panel, w/ cable management bar

A

3012IP-TCN488W-C5BBK

2U48

Cat.5 TELCO 100 BASE-T T568 B wiring patch panel, w/ cable management bar

B

Wiring Scheme
TELCO
25-pair
connector

P1

RJ-45
Modular
Jack 1
P2

TELCO
25-pair
connector

RJ-45
Modular
Jack 7
