Viabizzuno by Cirrus Lighting - Architectural Lighting Range Trasparenze Emergency Signage by Cirrus Lighting | Page 31

versione allarme acustico visivo incendio
con sorgente luminosa a led e 1 buzzer
piezoelettrici da 70 dB per preallarme e
allarme.
- the audible/visible fire alarm version with
led light source and one 70dB piezoelectric
buzzers for pre-alarm and alarm.
trasparenze 100x150 allarme
ECG
IP20
corpo nero led 6050K
black body led 6050K 2x1W 0,22
F6.168.72 corpo biancoled led 6050K
white body led 6050K 2x1W 0,22
F6.168.71
approvazione KEMA secondo la EN 60598-1+EN 54-3
KEMA approved to EN 60598-1+EN 54-3
30
100
24Vdc
trasparenze 100x250 allarme
24Vdc
ECG
IP20
F6.168.73 corpo nero led 6050K
black body led 6050K 2x1W 0,28
F6.168.74 corpo bianco led 6050K
white body led 6050K 2x1W 0,28
approvazione KEMA secondo la EN 60598-1+EN 54-3
KEMA approved to EN 60598-1+EN 54-3
30
100
trasparenze parete 100 allarme
24Vdc
ECG
IP20
60
corpo nero led 6050K
black body led 6050K 2x1W 0,22
F6.168.76 corpo bianco led 6050K
white body led 6050K 2x1W 0,22
F6.168.75
100
30
approvazione KEMA secondo la EN 60598-1+EN 54-3
KEMA approved to EN 60598-1+EN 54-3
