Vented Sidelight- Non-Impact AAMA Results
Product
Design Pressure Rating
Structure Performance( psf)
Water Resistance( psf)
Air Infiltration( cfm / ft2)
AAMA 101 Standard
8068, LLPR
DP30 + 45 /-45 4.5
0.02
HGD-LC30 94” X 83”
Energy Performacnce Rating- Non-Impact Hinged
Door Type
Hinged Non-Impact
Energy Star Climate Zones Door Style Glass Type North North Central South South Central U-Factor SHGC VT
Full Lite
3 / 4 Lite
LoE 3 366
*
*
*
*
0.25
0.14
0.30
LoE 3 340
*
*
*
*
0.25
0.09
0.18
LoE 3 Blinds
-
-
-
-
0.27
0.25
0.28
LoE 3 366 0.25 0.09 0.20
* * * *
Sound Transmission Class- Non-Impact Hinged
Product Specification STC
3080 Outswing Pemko ADA Sill( 1 " Special Glass)
35
28
3080 Outswing Extended Pemko ADA Sill( 5 / 8 " Standard Glass)
31
27
3080 Inswing Endura ADA Sill
( 1 " Special Glass)
31
26
OITC Product Specification
STC
6068, LP Outswing( 0.625 " Standard Non-Impact Glass)
29
25
6080 Outswing Pemko ADA Sill( 1 " Special Non-Impact Glass)
30
27
6080 Inswing Endura ADA Sill
( 1 " Special Non-Impact Glass)
29
24
OITC
Hinged Transoms
Transom Test Results- Non Impact
Transom Test Results- Non Impact
GTI 6020
Product
GTI 12020( with mullion)
GTO 6020
GTO 12020( with mullion)
Design Pressure Rating
Structure Performance( psf)
Water Resistance( psf)
DP80 + 120 /-120 12.00
DP75 + 120 /-120 11.25
DP80 + 120 /-120 12.00
DP75 + 120 /-120 11.25
0.01 0.01
0.01
0.01
AAMA 101 Standard
TR-LC80 71 1 / 4” X 24”
TR-R75
145 3 / 8” X 24”
TR-LC80 71 1 / 4” X 24”
TR-R75
145 3 / 8” X 24”
Type
Inswing
Outswing
Transom Test Results Impact
Transom Results- Impact
Product
Design Pressure Rating
Structure Performance( psf)
Water Resistance( psf)
( cfm / ft)
Test Standard
Type
GTI / GTO 6020
DP80
+ 120 /-120
12.00
TAS 201 / 202 / 203
Inswing &
GTI / GTO 12020( with mullion)
DP80
+ 120 /-120
12.00
TAS 201 / 202 / 204
Outswing
0.01 0.01
