Why choose the G5 Modular?
Excel G5 Modular
modular lightweight wheelchair
•
An almost unlimited combination of seat options to ensure an
Silver Seating
exact comfort fitting for your customer
Compatible
EN 12183
ISO 7176-19
The G5 ‘Modular’ is built with the modular system which is based on a simple
•
adjustable basic frame enabling various designs and options to be added.
Unique height and depth adjustable armrests, unique width
adjustable footplates
•
Multi configurable frame and backrest adjustments that can be
done retrospectively. Reconfigure the chair endlessly.
Specifications
Seat width:
35, 37½, 40, 42½, 45, 47½, 50, 55 and 60 cm
Seat depth:
40, 42½, 45, 47½, 50 and 52½ cm
Seat height:
45, 47½, 50, 52½ and 55 cm
Backrest height:
42½, 45 and 47½ cm
Overall width:
Seat width + 22 cm
Total length:
109 cm
Total height:
95 cm
Total weight:
12,9 kg
User weight:
Max. 130 kg
Available colours.
Why choose the G5 Modular Plus?
Excel G5 Modular Plus
aluminum lightweight wheelchair
•
Breathtaking new frame design and shape
•
High specification upholstery, four way stretch materials that
Silver Seating
Compatible
EN 12183
This wheelchair is distinguished from the G5 Modular series through the frame. The
are heat dispersant that reduce the threat of pressure related
frame of this chair is firmer and easily foldable, making the chair easier to transport.
soreness
This product comes standard with 24“ rear wheels.
•
Large combination of seat size options
Specifications
Seat width:
35, 37½, 40, 42½, 45, 47½ and 50 cm
Seat depth:
40, 42½, 45, 47½ and 50 cm
Seat Height (front):
44, 46½, 49 and 51½ cm
Seat Height (rear):
39½, 43½, 46 and 48½ cm
Backrest height:
43½, 46 and 48½ cm
Overall width:
Seat width +17 cm
Total length:
106 cm (incl. footrests)
Total height:
91 cm
Total weight:
21 kg
User weight:
Max. 130 kg
Available colours.
8
