Bone cutter C254AAC
Bone cutter used for minimally invasive preparation of bone and tooth structure . The special A-cut blades guarantee very quiet instrument running at the highest cutting capacity and maximum conservation of bone structure to be prepared . The long , slimline instrument neck provides excellent visibility during preparation . The hard ZrN ( zircon-nitride ) coating ensures the cutter meets the high demands placed on a high-quality surface during surgical bone preparation .
Application : Exposing and removing impacted wisdom teeth , apicectomies , preparation of bone structure and bone lids , separating teeth and tooth roots .
Crown cutter C34LT
New generation of crown cutters with TiN high-performance coating for optimal chip removal and smooth , low-vibration operation . The toothing with crosscut and overhead cutting edge ensures maximum cutting performance as well as a long service life , even when cutting non-precious metal crowns . The crown cutter C34LT . 315.012 is to be placed at an angle of 45 °. The crown cutter C34LT . 315.016 can be used both at a 45 ° angle as well as flat .
Notes on use : 1 . cut open the ceramic veneer with a diamond instrument ( K-diamond ) 2 . cut the metal framework with the crown cutter – optimal speed 160,000 rpm , contact pressure 0.5 N
C254AAC
Knochenfräser Bone Cutter Fraise à os
p 3
Shank |
L mm |
6,0 |
Size |
ISO |
Order No . |
012 |
� 1 / 10 mm |
|
|
|
|
FGXXL
• 506 316 415 298 ...
C254AAC . 316 ...
|
012 |
|
d max . |
d opt . |
FGXXL |
100.000 |
60.000 |
C34LT
Kronentrenner Crown Separator Coupe-couronne
dmax . 300.000 / opt . 160.000 p 5
Shank |
L mm |
3,5 |
6,0 |
Size |
ISO |
Order No . |
012 |
016 |
� 1 / 10 mm |
|
|
|
|
|
FG
•• 506 315 139 293 ...
C34LT . 315 ...
|
012 |
016 |
StarTec
d opt . 6.000 d max . 8.000 p 6
L mm |
1,5 |
1,5 |
Size � 1 / 10 mm |
130 |
130 |
Order No . |
ST2830RA |
ST2840RA |
ISO No . 804 204 ... |
099 524 130 |
099 514 130 |
Stufe • Step • Etape |
1 |
2 |
StarTec RA Porcelain Polishers
2-Step Polishing system with diamond particles , used for producing an intraoral highlustre polish on zirconium dioxide , lithium disilicate ( LS2 ), zircon-reinforced lithium silicate ( ZLS ) as well as hybrid-ceramic . The highly flexible polishing lamellae adapt to any surface structure thus creating perfect polishing results , even on areas difficult to polish such as occlusal surfaces . Recommended speed 6.000 rpm . Always use coolant , 50L / min , when polishing . External cooling should be used when polishing with lamellae polishers , which should be directed between the polisher and ceramic filling .
Orthodontic diamond finishing strips
For interproximal enamel reduction ( IPR ), also referred to as “ stripping “ or “ recontouring ”. IPR is a technique in which part of the enamel layer is removed to create sufficient space for orthodontic alignment .
Diamond-coated on both sides , the diamond finishing strips enable simple and precise reduction of the interproximal tooth substance . The flexible strips follow the natural contours of the teeth to provide optimal surface design .
The diamond finishing strips are available in 4 different thicknesses : 0,1 / 0,2 / 0,3 und 0,4 mm . Three different grit sizes are available , according to the colour coding ; yellow for superfine grit , red for fine grit and blue for medium grit . The stainless steel strips can be autoclaved and reused .
KDS
doppelseitig belegt double side coated diamanté e double face
KDSC 1 KDSF 2 KDSM 3 KDSF 3 p 5 KDSM 4
L mm |
147 |
147 |
147 |
147 |
147 |
|
Körnung • Grit • Grain
• 15 µ m
• 30 µ m
• 46 µ m
•• 30 µ m
•• 46 µ m
|
Stärke mm • Thickness mm • Epaisseur mm |
0,10 |
0,20 |
0,30 |
0,30 |
0,40 |
Breite mm • Width mm • Largeur mm |
6,0 |
6,0 |
6,0 |
6,0 |
6,0 |
Order No . |
KDSC 1 |
KDSF 2 |
KDSM 3 |
KDSF 3 |
KDSM 4 |
