dash .
A brand new , twin-spar steel frame was developed for the new DR-Z4S and DR-Z4SM . It is mated to a new aluminium subframe and an aluminium swingarm . Like the engine , it was designed to build on the previous model ’ s reputation for precise , agile handling and easy manoeuvrability . The new chassis is rigid , yet supple , meaning it can absorb impact and bumps on rougher terrain , and reduce rider fatigue .
Long-travel suspension on both the DR-Z4S and DR- Z4SM comes from KYB , specifically tuned for each model ’ s intended application . There is 280mm of front fork travel and 296mm of rear wheel travel on the DR-Z4S , while the DR-Z4SM has 260mm of front suspension travel and 277mm of rear wheel travel . Both have compression and rebound damping adjustment at the front and rear . There ’ s also preload adjustment on the rear shock .
Wheels are wire-spoked on both . The DR-Z4S is fitted with a 21 ” front and 18 ” rear , compared to the 17 ” rims in the DR-Z4SM . IRC GP-410 , dual purpose , tubed tyres are standard on the S , while the SM is shod with Dunlop SPORTMAX Q5A tyres .
There are disc brakes all round , and the tapered aluminium handlebars are equipped with half-waffle grips which distribute pressure across the palms and make the grips easier to hold , aiding control and greatly reducing rider fatigue . Foot pegs are wide and solid , providing sure-footing and a robustness to withstand impacts offroad . There ’ s also an aluminium under guard as standard .
Ground clearance comes in at a useful 300mm on the DR-Z4S , and 260mm on the DR-Z4SM . Seat heights are 920mm and 890mm and they weigh 151kg and 154kg , respectively .
Taking design cues from Suzuki ’ s RM-Z range , the new DR-Z4S and DR-Z4SM are designed to emphasise agile performance with a linear connection from front to rear . The focus was on establishing a bold horizontal line along the sides that cuts right from the front fender through to the tail .
Ergonomics also played a key role in the new design , and the DR-Z4S and DR-Z4SM are crafted as to not interfere in any way with the rider and their movement .
Lighting all-round is LED , from the single assembly headlight , rear combination lights , and indicators .
The DR-Z4S is available in Suzuki ’ s signature off-road Champion Yellow , and Solid Iron Grey , both with black rims . The DR-Z4SM comes in a new blue / grey colour scheme , dubbed Sky Grey , plus a Solid Special White , equipped with blue rims .
The ‘ DR-Z ’ decals on each side of the cowling , in front of the engine , are modern and simple . Following the horizontal line along the cowling , these decals feature a colourful gradation below the lettering that reflects the modern image of the DR-Z .
A range of accessories is also available , which includes items such as hand guards , a lower seat , and a rear carrier rack .
Pricing for the new DR-Z4S and DR-Z4SM will be confirmed in the New Year , with arrival set for the Northern Hemisphere summer , 2025 .
