Instructions
Door Assembly
1. Acquire Stainless Steel Over the Door Hook Organizer Rack
2. Using the vertical band saw, cut off the rightmost and leftmost hooks
3. Using a cordless power drill, drill holes with a 0.125’’ drill bit on each side of the over
the door hook rack (in locations where rightmost and leftmost hooks were)
4. Using the vertical band saw, cut off three 12” by 2.25” by 0.75” pieces of wood.
5. Using the vertical band saw, cut two 51” by 1.75” by 0.75” pieces of wood.
6. Using a cordless power drill, drill two centered holes with a 0.125’’ drill bit on each of
the 51’’ pieces of wood that are 0.5’’ from the origin.
7. Using a cordless power drill, connect the Door Assembly to the frame with 4 halfinch
wood screws (2 on each size)
8. Using a cordless power drill, drill centered holes that are 29.25’’ and 30.25’’ from the
origin on each 51’’ piece of wood with a 0.1875’’ drill bit.
9. Using a cordless power drill, drill centered holes that are 39.75’’ and 40.75’’ from the
origin on each 51’’ piece of wood with a 0.1875’’ drill bit.
10. Using a cordless power drill, connect the 51’’ piece of wood to a 12’’ long piece of wood
via the holes that are 29.25’’ and 30.25’’ from the origin. This should be done with two
3’’ wood screws.
11. Using a cordless power drill, connect the 51’’ piece of wood to a 12’’ long piece of wood
via the holes that are 39.75’’ and 40.75’’ from the origin. This should be done with two
3’’ wood screws.
12. Using the vertical band saw, cut two pieces of wood that are 4” by 1.25” by 0.75” and
two pieces of wood that are 4.5” by 1.25” by 0.75”.
13. Clamp one piece of wood that is 4.5” by 1.25” by 0.75” to one piece of wood that is 4”
by 1.25” by 0.75” perpendicularly.
14. Using a cordless power drill, drill centered holes between these two pieces with a 0.125’’
drill bit.
15. Using a cordless power drill, connect the two pieces in step 14 with a 2’’ wood screw.
16. Repeat steps 1315
17. Using a cordless power drill, drill centered holes .25’’ from the bottom of both 51’’
pieces of wood.
18. Using a cordless power drill, connect the two 51’’ pieces of wood via one of the 12’’
pieces of wood with 3’’ wood screws.
19. Using a cordless power drill, connect the pieces built in steps 15 and 16 to the holes
created in step 17 with 2’’ wood screws. See Figure 33 for finished view.
