( Three-way Active Monitors )

ADAM Audio S3H

( Three-way Active Monitors )

The S Series is the combination of many years of advanced inhouse engineering innovation at ADAM Audio and the latest computer aided design techniques . The range offers more bass extension and critical mid-range information , with a raised overall maximum output level but reduced distortion as well as forward-looking digital connectivity alongside its analog connections .
The drivers in ADAM Audio ’ s S series monitor speakers benefit from years of in-house research and development and take advantage of the latest advances in technology and materials science . Newly developed for the S series , ADAM ’ s Extended Linear Excursion ( ELE ) bass drivers employ the Symmetrical Magnet Assembly ( SMA ) to deliver optimized low-frequency reproduction with extended dynamic range and freedom from coloration . The ELE driver incorporates a rigid , yet lowmass honeycomb driver cone ; a highly efficient , self-cooling linear magnet assembly ; linear suspension and damping systems with a low-loss speaker surround ; a vented symmetrical voice coil ; and an optimized driver chassis / basket design . The S3H ’ s two 7 ” woofers extend response down to 30Hz , making the speaker suitable as a main monitor in medium-to-large control rooms , without the use of a subwoofer .
The ART ( Accelerating Ribbon Technology ) tweeters and midrange drivers incorporate a new approach to the Air Motion Transformer concept originally developed by Dr Oskar Heil . ADAM Audio has refined the original , innovative design , employing superior geometries and materials to achieve unprecedented audio fidelity . The newly developed tweeter design has become the embodiment of the transparent , highly defined , accurate audio for which ADAM Audio is now respected . For the S Series , the manufacturing process for each tweeter has been undertaken to an even higher standard of precision , with a more stringent post-factory testing regime . The S-ART tweeter is the result .
Utilizing the latest SHARC processing technology , the S series ’ custom DSP optimizes the system ’ s loudspeaker crossovers to deliver linear response over the entire frequency range and provides user sound-tailoring EQ as well as room tuning and voicing functionality . The DSP also handles limiter-based highfrequency driver protection , processes the signals from the AES3 digital inputs , and allows for various expansion options . Software updates can be executed easily via the system ’ s USB port , which also allows you to connect to computers and control DSP functions via software .
S series monitors were designed without compromise to be highprecision professional reference monitors that flawlessly reproduce any signal presented to their inputs . You can expect outstanding transparency , dynamic response , and flexibility in placement and operation — and an open , natural , and non-fatiguing sonic presentation that will continue to please your ears and allow you to effortlessly make wise decisions throughout lengthy recording and mixing sessions . ADAM Audio ’ s substantial cabinet construction is scientifically designed to minimize undesirable vibrations and their attendant coloration , while its rounded edges reduce diffraction distortion . Generous mathematically sculpted bass reflex ports on the front baffle help deliver bass reproduction with very low compression and allow positioning close to walls .
ADAM Audio ’ s monitor range has garnered rave reviews from audio experts and recording engineers worldwide . If you ’ re considering an upgrade to world-class monitoring , you ’ ll be in good company with ADAM Audio monitors .
