HOW TO PICK AND DECODE THE NEW FORD HU198 LOCK USING A MR LI ’ S ORIGINAL PICK & DECODER
In this step-by-step guide , we will provide you with detailed information about the lock , the tools required and the techniques involved in picking and decoding the new Ford HU198 lock . Let ’ s get started .
The Ford HU198 lock , which features 10 wafers and 5 heights ( code series : 0020001-0032003 ), was first introduced in Ford Fiesta models in 2017 . As you can see from the images below , the key blade is the same as the HU101 . However , the HU198 has got internal track cuts , a departure from the external track profile of the HU101 blade .
Example :
Reading Sprung Side
Reading Un-Sprung Side
1 2 3 4 5 6 7 8 9 10 4 2 2 4 5 4 4 2 1 3
2 4 4 2 1 2 2 4 1 3
The Pick : To pick and decode the lock we will use the Mr Li ’ s Original HU198 / Ford 2017 Twin Arm which suits HU198 door , ignition and boot locks .
Step 1 - Picking : Insert the tool in the keyway and without applying any tension determine where the wafers are . After you have located each wafer , apply tension and look for binding ( not moving ) wafers . Apply force with the lifter arm until all 10 wafers become springy / picked and the lock will open .
Picking Tip : The design of the Mr Li ’ s Original HU198 Pick allows you to unpick a wafer that is over-picked without releasing the tension . Simply go to the opposite side and un-pick .
Step 2 - Decoding : Once you have picked the lock , you can proceed to decode it . Re-apply tension and determine the cut height using the lifter arm and the scale on the body of the pick .
Decoding Tip : If you are unsure about the cut depth when reading on the sprung wafer , simply read the wafer on the opposite side of the tool and the arm will stop . The number of your reading must add up to 6 .
If you want to know more about Mr Li ’ s Original Pick and Decoders or Automotive Lock Opening Training Classes please visit www . keyprint . co . uk
