Roof Model 1
Improved Scale and Proportion
The three proportional house shapes form an identity for the concept which I could implement
throughout the whole building, from the roof structure, to the furniture and small interior design details.
The new roof model which I made using the three house shapes, can be seen in comparison to the
previous roof. The photo above shows how the size of the roof has been reduced, and the adjacent direct
comparison includes sketches of people, to show how the scale has become more appropriate for the
Geometry
Archetype
Home
Aesthetic
Scale
environment. In adjusting the roof proportions is
was also necessary to change the proportions
of the link, as shown in the model photographs
below. I am pleased with the composition of this
new roof as it strikes a better balance between
aesthetics and functionality. The design is in
proportion, appropriate for the site and the flow of
the interior is not defined by the geometry of the
roof, as specified earlier.
Aesthetic and Function
Roof Model 2
Golden Ratio
