MACHINERY YEAR
• JUN / JUL 2023
eco
NATIONAL SERVICE BACK-UP
1
MACHINERY YEAR
INDUSTRY 61
TESTED
WARRANTY *
RAPID VSC 240 100 BAR ELECTRIC HOT WATER & STEAM STAINLESS STEEL PROFESSIONAL PRESSURE WASHER
FEATURES
6-8
HOURS / DAY
Ÿ 304 Stainless Steel cover and chassis with bumper bars
Ÿ 4-wheels for ease of transport over uneven or soggy terrain o o
Ÿ Heats water to 90 C on full pressure and 150 C on steam stage
Ÿ Diesel boiler compatible with HVO ( bio diesel ) fuels
Ÿ low centre of gravity helps prevent toppling
Ÿ The powerful pump can draw from a water butt / IBC
Ÿ Boiler protection against low water pressure
Ÿ Simple adjustable temperature control
Ÿ Double pass heat exchanger guarantees hotter water with less fuel usage
Ÿ Fully protected electrics from water ingress
This stainless-steel built pressure washer has been developed the ideal 240V high performance hot and steam machine for contracting and agriculture .
SPECIFICATION
MAX PRESSURE ( BAR ) WORKING PRESSURE ( BAR ) MAX FLOW ( L / MIN ) PUMP TYPE BOILER – CLEAN BURN HOT WATER TEMP STEAM STAGE TOTAL STOP SYSTEM CHEMICAL APPLICATION MOTOR TYPE POWER RATING CABLE LENGTH HIGH PRESSURE HOSE GUN AND LANCE KIT DIMENSIONS L x W x H WEIGHT FUEL TANK SIZE )
* Recommended use 6-8 hours per day
200 100 12 SELF-PRIMING DIESEL FIRED 40 ° C - 90 ° C ( steam stage : 150 ° C ) YES Immediate stop type YES – injector type INDUCTION 2200W 5m 10m ( specify your choice ) YES - KTQ type 118 x 73 x 72cm 120kg 24 litre ( anti-spill )
WHY BUY ?
• 30 Second Delayed total stop – Protects Total Stop System
• 5m hi-vis yellow cable
• Parking Break
• New Rubber Handle Grips
• New Upgraded Accessories
• Super Series Pump
TESTED SERVICE BACK-UP
DD055 Item No . 5.5HP Description HONDA DRIVEN PETROL PRESSURE WASHER - 2000psi , 140 Bar V-TUF RAPID VSC240 100 BAR 24OV STAINLESS STEEL PRESSURE WASHER WITH DIESEL BOILER
V-TUF . CO . UK T + 44 ( 0 ) 1522 51 57 67 E ENQUIRIES @ V-TUF . COM
GET EQUIPPED
POWERED BY
WHY BUY ?
Ÿ QUICK , EASY , AND EFFECTIVE CLEANING OF DRIVEWAYS , PATIOS , VEHICLES , WINDOWS , AND OTHER DEMANDING JOBS WHERE AN ELECTRICAL POWER SUPPLY IS NOT AVAILABLE
Ÿ
Ÿ
163cc
5.5hp PETROL ENGINE
CHEMICAL INJECTION
LOW OIL ALERT
QUICK RELEASE NOZZLES ( 5 )
HOSE , GUN & LANCE KIT
2000 psi CLEANING
DESIGNED FOR OUTSTANDING PERFORMANCE WITH EXCELLENT RELIABILITY
THE STRONG , RIGID FRAME AND LARGE WHEELS DEAL WITH ROUGH TERRAIN
SPECIFICATION
MAX WORKING PRESSURE ( BAR ) FLOW ( litres / minute ) PUMP TYPE FUEL CAPACITY OIL SIGHT GLASS CHEMICAL INJECTION ENGINE BRAND DISPLACEMENT ( cc ) STARTING SYSTEM FRAME FINISH WHEELS SOUND LEVEL HIGH PRESSURE HOSE GUN AND LANCE KIT NOZZLES
DIMENSIONS ( L x W x H cm ) PACKAGING ( L x W x H cm )
140 13.2 TRIPLEX DIRECT DRIVE 3.1 LITRES YES YES HONDA 163 ( 5.5hp ) RECOIL STARTER BLACK POWDER COATING LARGE PNEUMATIC TYRES 107 dBA 10M 3 / 8 " QUICK RELEASE YES - QUICK RELEASE 5 QUICK RELEASE ( 00,15,25,40 & CHEMICAL ) 700 x 550 x 930 720 x 600 x 550
FEATURES
VERY TOUGH BUILD QUALITY LARGE PNEUMATIC TYRES
1
V-TUF DURAKLIX QUICK RELEASE GUN , LANCE & 10M 3 / 8 " HOSE YEAR
INDUSTRY TESTED
NATIONAL SERVICE BACK-UP
WARRANTY *
V-TUF XR11000 110V / 240V 110L 2200 / 3300W HIGH PERFORMANCE WET & DRY INDUSTRIAL VACUUM CLEANER
FEATURES
• THE 110L ROTO-MOULDED TANK IS ONE OF THE TOUGHEST PLASTIC TANKS YOU CAN GET – SHOULD LAST UP TO 10 YEARS MINIMUM
• NEW HEPA FILTRATION SYSTEM - PROTECTS THE MOTORS & THE AIRSPACE
• NEW HIGHLY VISIBLE YELLOW HOSE AND CABLE – PREVENT PEOPLE TRIPPING OVER THEM ON SITE .
• NEW REFLECTIVE STRIPE AROUND THE VACUUM HEAD – PREVENT PEOPLE BUMPING INTO OR TRIPPING OVER THE VACUUM ITSELF .
• ROBUST ACCESSORIES , ROBUST STAINLESS STEEL TUBES & 420MM WIDE FLOOR HEAD
• SIMPLE ELECTRICS - EASY TO SERVICE
• EXCELLENT SPARES AVAILABILITY
ACCESSORIES INCLUDED
1 . 5 METRE HEAVY DUTY YELLOW 38MM HOSE 2 . 38MM STAINLESS STEEL TUBES & ELBOW 3 . 420MM WIDE WET & DRY FLOOR HEAD 4 . 38MM ROUND BRUSH WITH HORSE HAIR 5 . 38MM CREVICE TOOL 6 . AQUA-DRY BASKET FILTER 7 . FOAM FILTER
1
5
2
4
3
7
6
MASSIVE SUCTION
6000 LTRS / HR
�
MULTIPLE MOTORS
TWIN TURBINE
�
ROBUST & SIMPLE
HARD WIRED
SPECIFICATION
5 METRE 38MM ANTI CRUSH YELLOW HOSE CABLE LENGTH : 5M MOTOR POWER : 110 VOLT = 2 X 1100W , 240 VOLT = 3 X 1100W AIR FLOW : 106 L / SEC SUCTION : 250 MBAR TANK SIZE : 110 LITRES WEIGHT : NETT : NETT : 28KG / GROSS 30KG DIMENSIONS : BOX : ( H ) 1000X ( W ) 540 X ( D ) 720MM
VAC : ( H ) 970 X ( W ) 530 X ( D ) 700MM
�
WHY BUY ?
MULTIPLE TWIN TURBINE MOTORS MAKE SHORT WORK OF ANY JOB 110 LITRE TANK WITH DRAIN PIPE FOR EASY EMPTYING ROBUST CHASSIS AND LARGE WHEELS MAKES MOVEMENT EASIER AUTOMATIC FLOAT LEVEL PREVENTS OVERFILLING .
Item No . XR11000 240V
Description 110L 3300W HIGH PERFORMANCE WET & DRY INDUSTRIAL VACUUM CLEANER - MADE FROM 70 % RECYCLED PLASTIC
V-TUF . COM T + 44 ( 0 ) 1522 787978
