FBP 3135 BalePack now available with film binding
»»
KUHN FARM MACHINERY has upgraded its fixed chamber round baler-wrapper combination machine by making its popular film binding technology available as an option.
Following on from the successful launch of KUHN’ s film binding system on the iBIO + last year, KUHN has now introduced the bale wrapping system on the latest version of its FBP 3135 BalePack machine.
‘ a tighter, better sealed and more consistent finish.’
KUHN’ s twin satellite film binding system uses two film reels to bind the cylindrical side of the bale and offers several advantages compared to other film binding systems, not least the ability to use standard sized rolls( 25 µ m, 1500m, 750mm) therefore eliminating the need to order separate binding and wrapping film. The KUHN system reduces film usage by up to 30 % by pre-stretching prior to application and boasts quicker and easier roll loading thanks to a user-friendly system which hydraulically folds the film reels into their loading / unloading position.
The FBP 3135 Bale Pack can also be used with conventional net binding: switching between film and net binding is quick and simple as the two systems are separate, making it easy to switch from one system to the other for different crops. In either specification, the FBP delivers high output productivity in conjunction with consistent bale formation and a reliable wrapping mechanism.
The FBP 3135 is available with two different intake rotors – the OPTICUT 14 or OPTICUT 23 – both with Hardox tines. Each version shares the same 2.30m pick-up which features cam-track technology for improved contour following for cleaner grass collection. The FBP uses KUHN’ s INTELLIWRAP system, which uses vertically mounted film pre-stretchers to prevent grass being deposited between layers of film for a tighter, better sealed and more consistent finish. The wrapping unit is also fitted as standard with KUHN’ s film break sensor, and can be specified with the company’ s 3D wrapping system for perfectly sealed bales which maintain their shape well and are better protected compared to conventionally wrapped bales.
Mosterley Farm, Cound Moor, Shrewsbury SY5 6BH Tel: 01694 731777 Fax: 01694 731761 www. abccomms. co. uk
AVANT TO LAUNCH NEW E6 ELECTRIC MODEL AT PLANT & MACHINERY SHOW
»»
AVANT WILL LAUNCH ITS new e6 electric model at the Plant and Machinery Show at UK Construction Week at the Birmingham NEC in October.
The fully electric batterypowered loader in the same size class as the Avant 600 series, offering zero emissions, extremely low noise and minimal running costs.
The battery powered loader is especially suitable for indoor use where ventilation is limited. This means that the operator and workers are not exposed to exhaust emissions which create health risks. A further benefit of a battery driven machine is the extremely low noise level, meaning it can be used in noise restricted areas. This is especially useful for demolition and construction contractors, farms and equestrian businesses, as well as some industrial applications, where noise needs to be kept to a minimum.
The loader has an integrated battery charger, which makes it possible to charge batteries using a 230 volt / 16A power outlet. The e-series can also be operated while charging the batteries.
The Avant e6 is the first loader in the world to use lithium battery technology. The e6 is equipped with a 288 Ah lithium battery and two electric motors: a 6kW motor for driving the machine and a 2kW motor for loader boom operation and auxiliary hydraulics. An onboard charging unit is included which enables charging from any 230V / 10A power outlet. Auxiliary hydraulics flow is 30 l / min, which allows working with various Avant attachments, including hydraulic hammer and various grapples.
Lithium-ion battery technology provides significantly better performance compared with lead-acid batteries. In light use lithium battery performance is around 30 % better than lead-acid batteries- in heavy use the operating time is up to three times longer.
The battery on the e6 can also be charged from 0-100 % in one hour when using a rapid charging station. It’ s also lighter which is useful when working in construction sites where the machine weight is relevant.
Avant manufactures a wide range of compact, 4-wheel drive machines, which can be fitted with a very comprehensive range of accessories to make general maintenance and equestrian jobs, easy and less labour intensive.
www. avant. co. uk
