KOENIGSEGG GEMERA
SPECIFICATION
12
ENGINE Koenigsegg Tiny Friendly Giant( TFG) twin-turbo Freevalve 3-cylinder 2.0-litre engine Displacement: 1988 cc Bore: 95 mm Stroke: 93.5 mm Compression ratio: 9.5:1 Power output: 600 hp( 440 kW) at 7500 rpm( red line at 8500 rpm) Torque: 600 Nm( 442.5 lb. ft) from 2000 rpm to 7000 rpm. Lubrication: Dry sump Engine weight: 70 kg E-motors: Three electric motors- one for each rear wheel with 500 hp and 1000 Nm each and one E-motor on the crankshaft with 400 hp and 500 Nm to power the front wheels( together with the ICE)
ENGINE MANAGEMENT Koenigsegg engine control module. Flex fuel capability including E100, Methanol and sun fuel. High power ion sensing coil-on-plug ignition system.
POWER OUTPUT Total output: 1700 hp / 3500 Nm, including Hydracoup Max wheel torque: 11,000 Nm at ICE 4000 rpm Electric power: 800 kW( 1100 hp) combined( counting E-motors separately – 1400 hp) Performance: 0-100 kph( 0-62 mph) in 1.9 secs. Top speed: 250 mph( 400 kph)
RANGE ICE only range: up to 950 km. Electric range: up to 50 km. Total range: up to 1000 km
� TRANSMISSION Mid-mounted Koenigsegg ICE + E-motor Hydracoup Direct Drive transmission powering the front axle. Front axle has torque vectoring capability and can be disconnected to save energy in EV-only mode. Rear axle: Independent E-motors with independent transmissions enabling torque vectoring and reverse. Rear transmissions equipped with wet clutches for decoupling, for range mode.
CHASSIS �arbon�fibre monoco�ue with wheel to wheel stiffness 40 KNm. Front and rear aluminium sub-frames.
BODY SHELL B-pillarless, two-door coupe with fully accessible four-seat interior. Carbon fibre body �anels� �isible carbon fibre on front and side splitters and venturi.
STEERING Rack and pinion electric powerassisted steering, with active rear wheel steering
SUSPENSION Double wishbones and adjustable gas-hydraulic shock absorbers, with
electronically adjustable ride height. Adjustable lightweight anti-roll bars front and rear.
ELECTRONIC STABILITY / TRACTION CONTROL Koenigsegg Electronic Stability Control( KES). Traction control: Wet / normal / track
ASSISTED DRIVING Autonomous Driving Level 2 ADAS, adaptive cruise control, Lane assist, Park assist, Surround-view cameras.
BRAKES Ventilated ceramic discs, Front: 410 mm diameter, 38 mm 6-piston. Rear: 395 mm diameter, 32 mm 4-piston. Koenigsegg callipers with ceramic pistons. Electric brake booster and ABS.
WHEELS / TYRES �oeni�se�� �ircore carbon fibre wheels with centre locking( optional) Front: 10.5 x 21-inch Rear: 11.5 x 22-inch with Michelin Pilot Sport 4S( or optional Michelin Cup R3) Front: 295 / 30 ZR21 Rear: 317 / 30 ZR22
DIMENSIONS Length: 4975 mm Width: 1988 mm Height: 1295 mm. Ride height: 117 mm front(+ 35 mm) / 117 mm rear. Wheelbase: 3000 mm. Kerb weight: 1850 kg Fuel capacity: 75 litres. Load volume( rear and front): 200 litres.
