105
considered as a charm-stone against spells. Black Onyx also symbolizes
equilibrium and inspiration.
BRIDGES MADE OF TITANIUM
Photo Info : RM 026 TOURBILLON
These components in grade 5 titanium with black PVD treatment. This
provides the whole assembly great rigidity, as well as precise surface
flatness which is essential for the perfect functioning of the gear train.
VARIABLE INERTIA, FREE SPRUNG BALANCE
The free-sprung balance provides better reliability in the event of
shocks, movement assembly and disassembly. It also guarantees
better chronometric results over an extended period of time.
Tonneau case - Limited edition: 15 unique pieces, 18k white gold gemset case.
CALIBER RM026: manual winding tourbillon movement with hours,
minutes and power reserve, inspired by the RM 019.
Dimensions: 45 mm x 39.70 mm x 12,60 mm.
CERAMIC ENDSTONE FOR THE TOURBILLON CAGE
This reflects a technical and long-term view towards the elimination of
wear phenomena, resulting in improved technical tribology.
TORQUE LIMITING CROWN
MAIN FEATURES (MANY OF WHICH ARE MAJOR TECHNICAL
INNOVATIONS)
This additional security system prevents from accidental overwinding,
which could cause damage to the winding stem or putting extreme
pressure on the mainspring barrel. The crown is set with precious
stones or semi-precious stones depending on the version.
POWER RESERVE
BARREL PAWL WITH PROGRESSIVE RECOIL
Circa 48 hours. This function is displayed using a newly designed
differential power reserve system, with a printed red line on a moving
disc located between 10 and 11 o’clock.
This device permits a profitable winding gain (circa 20 %), especially
during the winding start. It is also helpful in the distribution of the
mainspring’s internal tension.
MOVEMENT
OTHER FEATURES
Two creatures adorn its precious movement, writhing and searching
within the tourbillon movement, whilst simultaneously holding the
precious tourbillon movement in place.
We can admire a ruby & diamond encrusted 18k white gold snake and
an emerald & diamond encrusted 18k white gold snake with red coral
tongue. But there are several other versions available of these coupled
snakes, such as precious stones encrusted or semi-precious stones
encrusted, or engraved stones, and even enameled bodies. Each model
is an unique piece. It took many hours and extremely precise work to
engrave by hand the scales of these two exceptional jewellery pieces.
Serpents in mythology have complex roles that can be either good
or evil. In connection with the positive properties of Black Onyx they
however take on a protective role, representing the potent guardians
of temples and other sacred places. Thus, they are natural guardians of
treasures or sacred sites that are intimate and require protection.
BLACK ONYX BASEPLATE
Onyx is a variety of cryptocrystalline quartz chalcedony composed
of silicium dioxide, (SiO2). The rectilinear black and white parallel
stripes version is part of the agate types. The fully black type is called
Black Onyx, and is said to be able to deflect harmful energy down
to the earth, while providing stability. For this reason, Black Onyx is
- Movement dimensions: 30.20 mm x 28.60 mm - Thickness: 4.97 mm
- Tourbillon diameter: 12.30 mm
- Balance wheel diameter: 9.12 mm
- Number of jewels: 21
- Balance: Glucydur, 2 arms, 4 setting screws, inertia moment 10
mg.cm2, angle of lift 53o
- Frequency: 21,600 vph (3 Hz)
- Balance spring: Elinvar by NIVAROX
- Shock protection: KIF Elastor KE 160 B28
- Stone setting in white gold
- Barrel shaft in nickel-free
chronifer (DIN x 46 Cr 13
+ S) with the following
characteristics:
stainlessantimagneticsuitable for tempering
