PRODUCTS
HFA Series One Systems targets
goes linear integrators with OPALine system
DESIGNED TO deliver ‘high output
and dynamics’ combined with
‘extreme linearity and delity’,
Next-proaudio’s new HFA speaker
series comprises of fully powered
PA systems with custom made
components seated in birch plywood
enclosures.
NEXT-proaudio’s HFA series
Manufactured entirely in Portugal,
a 2,200W RMS Class-D ampli er
sits at the heart of the system with
an automatic standby mode that
activates when the amp detects
no input signal. Integrated DSP
with A/D-D/A low noise convertors
provides eight selectable presets
that can be accessed by a selector
located on the front module, via
USB remote control, or via the
supplied Soundware software.
Editable parameters include, EQ,
delay, and HP/LP lters.
To extend the low frequency
response, the HFA speakers can
also be paired with HFA subwoofers
available in three models: 12-, 15and 18-inch.
Shipping: TBC
Web: www.next-proaudio.com
CONSISTING OF single box vertical
array loudspeakers and an 18-inch
powered subwoofer, One Systems’
new On Point Audio branded OPALine
powered three-way vertical line
array system is being targeted for
both portable and xed installation
applications. Additionally, the
manufacturer has debuted an allweather loudspeaker in the form of
the 118IM-Sub.
The OPALine series comprises
vertical array loudspeakers featuring
four 8-inch woofers and two
compression drivers supplying its
line array waveguides. The 18-inch
sub also houses the system’s dualchannel 2,000W peak, Europeandesigned ampli er and processing
electronics.
The vertical transducer
con guration provides 90-degree
horizontal dispersion and, with the
two HF waveguides operating in
parallel from 1,000 to 2,000Hz,
a 40-degree vertical pattern that
according to the manufacturer
delivers ‘excellent intelligibility in
One Systems’ sub and OPALine
reverberant spaces by maximising
direct sound’.
The four NP8 woofers have the
same acoustical radiating area as
standard 8-inch cones, and can be
used both as a line array speaker or
stand-alone as a traditional passive
speaker.
The subwoofer is housed in a
tour-grade 18mm marine plywood
enclosure with a dual-pole
suspension system and rear-mounted
castors. The system can be groundstacked using the built-in M20 screwon dual-pole mount system or own
for installations using the optionally
available eyebolt kits or On Point
Audio’s PTB pan and tilt bracket.
The PTB bracket enables
mechanical steering of the array’s
output up to 35-degrees horizontally
and vertically in 5-degree increments.
There is also an optional kit that
covers its handles for a more
professional look.
The other new product from the
American manufacturer, the 118IMSub, joins its line of copolymer based
all-weather loudspeakers to provide
integrators with extended low end in
a very small footprint.
The speaker has been built using
the One Systems 18I/O extended
bass transducer featuring the
company’s patented Inside/Only
(I/O) voice coil design. The mediumdensity polyethylene enclosure is
optimised for high UV exposure and
harsh environments, and despite its
compact size – approx. 60 x 50 x
53cm – has a frequency response
of 40-120Hz (+3dB) and a nearly
omnidirectional coverage pattern.
The speaker has been designed to
be pole mounted. All external rigging
and suspension hardware, as well
as the metal grille, has been built
using 304-grade stainless steel. The
structural internal rigging is made
with high-strength aluminium, the
grille is made using a three-layer
‘rain shield’ design to minimise
direct rain contact with the system’s
transducers, and the vented design
also allows for easy moisture
drainage from the interior of the
enclosure.
Inputs for the speaker consist of
a ve-pin barrier strip. Additionally,
a weather cover is provided with
an integral gland nut connector for
outdoor applications, capable of
accommodating cable diameters
from 7mm to 12mm.
Shipping: Now
Web: www.onesystems.com
SRP series brings studio quality to installs
SONODYNE HAS debuted a new
line of studio monitors branded
the SRP series. The new series
aims to remove colouration while
increasing rigidity and extending
low-frequency response.
The range currently comes in two
formats. The Pro Series – serving
studio applications – consists of
ve models: 350 (3.5-inch), 400
(4.5-inch), 500 (5.25-inch), 600
(6.5-inch), and 800 (8-inch); whilst
the 200 Series – 201 to 205 (3.5inch to 8-inch) has been designed
for custom install applications.
All models are two-way active
near eld monitors housed in the
same die cast moulded enclosure
with custom waveguides. Internal
DSP with high quality A/D and
D/A convertors is employed for
the crossover and also provides
0.75dB step HF and LF room
compensation EQs at the rear. On
the front is a level control ranging
from mute to +6dB with centre
detent at 0dB.
The SRP 350, 400, 500, 600, 800
Shipping: Now
Web: www.sonodyne.com
