LMS
LMS
Signal Tower
ON
OFF
LED
IP65
Φ60
NPN/PNP
Open-collector
When ordering the clearlens Signal Tower type, be
sure to add "-Z" at the end
of the part number when
ordering
Versatile, cost and energy efficient LED Signal Tower for every need.
Reflection
System
High visibility
from any angle
FEATURES
• PATLITE’s exclusive hybrid prism-cut lens designed for enhanced visibility from any direction and
distance.
• Original Dual Reflection System for enhanced light diffusion; creating bright, distinctive illumination
while saving energy.
• Pole-mount installation.
• Interchangeable Modules need no re-wiring, even after installation.
• Main body is constructed of ABS resin with superior resistance to impact and heat.
• Lens is made of superior impact resistant and light translucent AS resin.
• Available colors are in Red, Amber, Green, Blue, and Clear/White.
• Has the CE mark and conforms to the requirements for the EC directive.
• Is a UL Recognized Component (File No. E215660)
AVAILABLE BY SPECIAL ORDER
• Model LMS-U: Silver Color Body (FB060 type).
Easy to add and remove
•
When adding or removing
modules, the center shaft that
matches the amount of tiers has
to be purchased.
How to Order
Interchangeable LED Modules
Changeable color sequence: Easy to add/
remove up to 5 colored modules even
after installation.
Note: LED modules of the same color within a
signal tower will light up simultaneously.
Wiring doesn't change
•
The LED Module colors correspond to the
wiring, so re-wiring is not necessary.
LMS-502L- RYGBC-Z
Tiers
1~5
Rated Voltage
02: AC/DC 24V
LED Color
R: Red
Y: Amber
G: Green
B: Blue
C: Clear/White
(Top to bottom)
Lens Color
Blank: Colored Lens
Z: Clear Lens
Mounting
Blank: Pole with Circular Mounting Bracket
K: SZ-020 Pole Mount
L: SZ-013 Pole Mount
80
