RFT
RFT
Audible Alarm & LED Tower
LED
90dB at 1m
32 Alarm Sounds
IP54
115
NPN
Open-collector
An LED Rotating Light with built-in alarm sounds
controllable by binary or bit input for a maximum of 32
sounds!
•
•
•
•
•
•
•
FEATURES
Sound reduction feature to drop the volume by about 10dB (at 1m) when an input signal is received (Binary Mode only).
Using an SD Card can allow customization of one sound group to be re-arranged using any of the pre-installed sounds.
Compliance with the RoHS Directives makes it environmentally friendly.
Complies with EU directives and includes the CE mark (for 24V type).
Can be controlled with NPN open-collector transistor inputs.
Side access design enables easy
post-installation maintenance
A side panel access allows easier volume adjustment.
Produces a loud sound of up to 90dB (at 1m)
Side Access
How to Order
RFT-24A-R
Rated Voltage
24 : DC 24V
100: AC 100V
220: AC 220V
Sound Type
A: A Type
C: C Type
D: D Type
E: E Type
Globe Color
R: Red
Y: Amber
G: Green
B: Blue
The sound reduction function reduces the
volume by approx. -10dB (at 1m), a feature ideal
for use at night time together with a timer or
sensor.
Type E
Sound Reduction
Beep (slow intermittent)
Stutter + Bell
Inverted Reveille
Annie Laurie
Stutter (rapid intermittent)
Bell (clear high-pitch)
Melody Chime
Galactic Motor
London Bridge is falling down
Chime
Ringing Phone
Mary had a little Lamb
Yelp (rapid siren)
Call Sign
Two Tone
Camptown Races
Rapid Hi-Lo
Train Ride
Alarm Clock
Amaryllis
Melody Chime
Galloping Hi-Lo
Ringing Hi-Lo
Mozart Symphony No. 40
Synthesized Piano
186
Alien Chatter
Fur Elise
Ave Maria
Synthesized Bell
Falling Crystals
Bach Minuet in Gmaj
Grandfather’s Clock
