LKEH
LKEH
MP3
MP3 Voice Annunciator & LED Signal Tower
LED
32 Alarm Sounds
105dB at 1m
IP53
(LED) Φ100
NPN
Open-collector
Get the attention you need with the PATLITE fieldprogrammable LKEH Series Hybrid Signal Tower with
audible alarm.
•
•
•
•
•
•
•
•
•
FEATURES
The pre-recorded type offers 32 sounds in one unit with 8 bit input and 32 binary input channel capability.
The message capacity for the LKEH-FV is 63 seconds (64kbit/s) with 5 bit input and 31 binary input channel capability.
The LKEH-FV is field-programmable with an SD Card (sold separately).
Visible from great distance with ultra-bright LEDs and 100 diameter lens.
A 2G vibration resistant design allows safe use in a high-vibration environment.
One common wire makes it easy to control both the audio and LED inputs.
Volume is adjustable from 0 to 105dB (at 1m) to fit various environments.
Compliance with the RoHS Directives makes it environmentally friendly.
Complies with EU directives and includes the CE mark (for 24V type).
AVAILABLE BY SPECIAL ORDER
• PNP open collector transistor type.
• AC 120V type
• UL Listed (File No. E215660, for 24V type only).
Insert an SD Card
into the slot
Ultra-bright
LED
How to Order
LKEH-402FVUL-RYGB
Model
Tiers
1-4
Rated Voltage
02: DC 24V
10: AC 100V
20: AC 220V
UL Conformity
None: No Conformity
UL: UL Standard
Sound Type
FV: Voice Synthesizer
FA: Type A
FC: Type C
FD: Type D
FE: Type E
Color
R: Red
Y: Amber
G: Green
B: Blue
C: Clear/White
(Top to bottom)
105dB
Output
(at 1m)
Use of Copyrighted Material
184
PATLITE Corporation has not applied for permission to use certain copyrighted music or songs recorded for Type-A, Type-C and Type-D melody
charts outside of Japan. Therefore, please contact the local copyright association for permission before using the product in case this product
is used outside of Japan. melody chart Type-E is recommended for use outside of Japan as this playlist does not include copyrighted music or
songs, and permission is not required.
