MP3
Model EHV
Model BSV
Model LKEH
STEP 1
Model RFV
Model BDV
Model BKV
Model FV-127JP
Get the New Playlist Editor 2
The Playlist Editor 2 is free from PATLITE. Download the PATLITE Playlist Editor
2 from our Global Home Page, or contact us by E-mail, which can be located
on the back of this catalog.
STEP 2
Get the Recommended SD Card (Model SDV-2GP)
The SDV-2GP is an SD Card approved and supplied by PATLITE.
(The PATLITE Corporation is a member of the SD Card Association.)
STEP 3
Create the MP3 messages
Convert any message into MP3 data.
(Remove "ID3" tags and be sure the sample rate is the standard rate of 64kb/
sec for PATLITE products and the SD Card is formatted for "FAT16".)
STEP 4
Save the MP3 messages on the SD Card
Use the Playlist Editor 2 to create a playlist and save it on an SD Card.
(Refer to the product manual for detailed information)
STEP 5
170
Load the MP3 Data into the Product
Programming can be done right out in the field!
Insert the SD Card into the Product's SD Card slot and listen for the Beep that
tells it's programming (Refer to the product manual for detailed information
on programming).
