BD
BD
Audible Alarm
AC/DC 24V Only
AC/DC 24V Only
90dB at 1m
4 Channels / 32 Sounds
IP54
80
NPN
Open-collector
The BD Series can play melodies, chimes and alarms with
variable audible control and a compact, but loud speaker.
FEATURES
• Maximum output level of 90dB (at 1m) is suitable for use in a noisy factory.
• 32 pre-recorded sounds in one unit to be used for various applications.
• Sound output level and sound group can be selected by rotary switches stored behind the front panel for easier operation, even after
installation.
• Select a sound group to playback 4 pre-recorded sounds.
• A new sound group can be created from the 32 sounds by using an optional memory card (sold separately).
• Compliant with the RoHS directive
• Has the CE mark and conforms to the requirements (for 12V/24V type) for the EC directive.
• Is a UL recognized component (File No. E24210).
AVAILABLE BY SPECIAL ORDER
• Binary input controlled 15 sound playback model.
• PNP open collector transistor type.
Dimensions
80
How to Order
79.5
15.2
17.2
BD-24A-J
Rated Voltage
Mounting Hardware
Color
24 : DC 24V
100: AC 100V/220V
J: Ivory White
K: Dark Gray
Sound Type
A: Type A*
C: Type C*
D: Type D*
E: Type E
15.5
*Copyright laws limits availability to Japan only.
162
Front Cover Mobility Range
(Unit: mm)
