■ Reduces the "Blinding Light" Effect
Flat Surfaced Body
CLK
Water Resistant
Construction
Conventional Magnification Lens
New "Micro-array" Lens
Tempered or Acrylic Glass
Micro-array Lens
Reduces the "Blinding Light" Effect
Angled Body and Flat Surface
The side body angle was designed to prevent dirt accumulation, and
for water and oil to roll off the surface. The LED lens retains a simple
flat-surface for lighting and to help when wiping it down.
This design conforms to the Photobiological
Safety of Lamps and Lamp Systems (Compliance
:EN62471- 2) in the Exempt Risk Group, which
determines that no immediate retina damage is
done.
Option
Standard
Option
Angle Adjustment Bracket
Surface-mounting Bracket
Just sliding the body onto the bracket makes
attachment easy; and it locks in place with
a locking screw (which is hidden from the
front). (Aluminum Body Only)
The Worklight can be freely adjusted up to
60° up and down from the center. (With a
scale at 10° step marks and screws to lock it
into place.)
A space-saving flush-mount bracket. (Limited
board thickness and lead wire specification of
6mm or less; M12 connector specification of
r
3mm or less) (Models 3 S-AG/3 C-AG Only)
CLK-001
SZ-320KS
One-touch Installation
SZ-330KP
0KP
Daisy Link at a maximum of 5 Units
m
M12 Quick Disconnect
4-wire M12 Socket Cable, 5m (No. 1536308)
4-wire M12 SUS Socket Cable, 5m (No. 1552447)
4-wire M12 Link Cable, 0.6m (No. 1518892)
4-wire M12 SUS Link Cable, 0.6m (No. 1552638)
Manufacturer: Phoenix Contact Corp
Manufacturer: Phoenix Contact Corp
Product Lineup
Specifications
Length
Side-exiting Cable Series (S)
M12 Quick Disconnect Series (C)
M12 Quick Disconnect Daisy Link Series (CL)
Stainless Steel (SUS) Body Series (C-SG/C-SA)
2S
200
mm
6500K
5000K
3S
600
mm
3CL
3C
6500K
6500K
6500K
5000K
5000K
6S
mm
3C
6500K
5000K
300
6C
6CL
6800K
6500K
6500K
5000K
5000K
SUS &
Special Lens
* Up to 4 units
* Only 1 Unit
5000K
SUS &
Special Lens
157
