SKH-EA
For more details on Model DEB
Refer to the “Replacement Bulb”
Section at the end of this Catalog
Revolving Warning Light
SKH-EA
Model DEB LED Lamp
Recommended Product
Bulb
IP23
Φ100
Best-selling Revolving Warning Light for wide range of
applications.
•
•
•
•
•
•
FEATURES
Indoors allows upright, inverted, and sideways installation; outdoors allows upright installation only.
Has the CE mark and conforms to the requirements (for 12V, 24V type only) for the EC directive.
Dome is made from superior weather-resistant and light-translucent acrylic resin.
Rotating parabolic reflector to enhance visibility from a distance.
Vibration-resistant automobile bulb for extended bulb life.
Available Colors are Red, Amber, Green, and Blue.
Specifications
Series
Model
SKH-12EA
USA Version SKH-24EA
SKH-120EA
SKH-12EA
Standard SKH-24EA
Version SKH-100EA
SKH-200EA
Bulb
Rated
Current
Flash Rate
Voltage Consumption
(fpm)
Ratings Repl. No.
DC 12V
0.8A
12V 10W
9
DC 24V
0.5A
24V 10W
10
AC 120V
0.07A
12V 5W
12
DC 12V
0.8A
12V 10W
9
170
DC 24V
0.5A
24V 10W
10
AC 120V
0.065A
12V 5W
12
AC 200V
0.03A
Dimensions
ø94
How to Order
400g
SKH-
600g
Model
400g
600g
Rated Voltage
12 : DC 12V
24 : DC 24V
100: AC 100V
120: AC 120V
200: AC 200V
EAColor
R: Red
Y: Amber
G: Green
B: Blue
0°
Mounting Hole
3- ø5
Wire Entry Hole
12
64
146
76
Mounting Dimensions
ø70
12
3-M4
ø100
Mass
Nameplate
120°
(Unit: mm)
133
