KPE-A
KPE-A
Flashing/Rotating Light
LED
IP23
Φ162
Revolving Warning Light featuring maintenance-free LED’s,
Corrosion-proof plastic and adjustable flashing cycles.
•
•
•
•
•
•
•
•
•
FEATURES
Enhanced design with special high-intensity illumination to improve light diffusion and ensure sufficient brightness, even outdoors.
Internally adjustable flashing cycle between 50 and 200 times per minute.
Extended long-life with LEDs so no bulb replacement is needed, perfect for "hard-to-service" locations.
Indoor installation can be upright, inverted or sideways; Outdoors is for upright only.
With an electronic rotating light system, no worn-out motors to replace.
Main body is made of special weather-resistant resin.
Dome is made from superior weather-resistant and light translucent acrylic resin.
Stainless mounting bolts with corrosion-proof screws.
Available Colors are Red and Amber.
Specifications
Model
Rated Voltage
KPE-100A
AC 100V
KPE-220A
AC 220V
How to Order
Power Consumption
Flash Rate
Mass
Continuous: 4W
Flashing: 9W
50 - 200 rpm
60 fpm
1.5kg
KPE-
A-
Model
Rated Voltage
100: AC 100V
220: AC 220V
Dimensions
Wiring
19
ø120
°
61
122
Mounting Hole
3- ø9
Wire Entry Hole
ø12
120
190
203
Mounting Dimensions
3-M8
ø162
Color
R: Red
Y: Amber
Nameplate
Common Yellow
30
120°
Rotation Green
Flash
Red
(Unit: mm)
Power
White
Power
Black
Ground (Green/Yellow)
External
Contact
Signal
Wire
Fuse (1A)
Power
Supply
(Non-polar)
