LGE
LGE
Signal Tower
LED
1 Alarm Sound (FB Type)
85dB at 1m
IP54
Φ100
NPN/PNP
Open-collector
Large Signal Tower featuring enhanced visibility and
downward illumination, designed for large machines.
FEATURES
• PATLITE's large prism cut lens to enhance illumination in the downward direction. (Lens Size:
φ100mm x 60mm high)
• The FB type offers a flashing and continuous lighting pattern.
• A built-in buzzer (FB type) has a sound of up to 85dB (at 1m).
• Direct mount Installation.
• Interchangeable Modules need no re-wiring, even after installation.
• Lens is made of superior impact and heat resistant polycarbonate resin for superior durability
and illumination.
• Both NPN and PNP compatible for the DC24V type; NPN compatible with the AC 100/220V type
only.
• Available Colors are in Red, Amber, Green, Blue, and Clear/White.
• Has the CE mark and conforms to the requirements for the EC directive. (for 24V type)
Triple Reflection System
PATLITE’s triple-reflection system
creates an even brighter and
distinctive illumination with its
exclusive hybrid prism-cut lens
for 5 color LED module variations.
Interchangeable LED Modules
How to Order (Pre-assembled)
LGE-402FB-RYGB
Tiers
1~4
Rated Voltage
02: AC/DC 24V
10: AC 100V
20: AC 220V
LED Tiers are changeable, even after
installation.
Note: Shafts that match the number of
tiers also has to be purchased.
How to Order (Module)
Base Unit
LED Light Module
LGEBC- 24 FB
Model
Rated Voltage
24: AC/DC 24V
100: AC 100V
120: AC120V
110
Type
Blank: Continuous Lighting
FB: Flashing/ Alarm
Color
R: Red
Y: Amber
G: Green
B: Blue
C: Clear/White
(Top to bottom)
Shafts (One Pair)
LGEM-24- R
Type
Blank: Continuous Light
FB: Flashing/ Alarm
Model
Rated Voltage
24: DC 24V
LGSHAFT- 1
Color
R: Red
Y: Amber
G: Green
B: Blue
C: Clear/White
Tier
1: 1 Tier
2: 2 Tiers
3: 3 Tiers
4: 4 Tiers
