A smooth-surfaced body without any metal exposed
LS7
By changing the surface of the body into a smoother form, the
adhesion of water and dust is reduced. Also, the structure does
not have screws, shafts, etc., exposed, which gives comfort for
applications in the lithium ion battery manufacturing and food
processing industries. And, with the outer lens structure, the
risk of environmental stress cracks due to oil mist is reduced.
The lens cover is made of shock-resistant polycarbonate.
A sound heard throughout various environments
In addition to the existing lead wire, M12
connector quick disconnect is also available.
Moreover, when moving to carry and to go out of
f
the device, it is possible
to detach it easily with Speaker Horn (Alarm Type)
the M12 connector.
Frequency graph of a metal-working shop sound
d
mixed with buzzer2 alarm. (Inter-corporate
e
Measurement)
* Buzzer1 (H type or C type) is measured at 2000Hz.
Easy attachment, no need for Relay Box
In addition to the conventional three-bolt installation, a twobolt installation from the upper mount has been added to help
make a smoother installation. Therefore, by using the mount
as a relay box, it reduces the manufacturing cost for an extra
relay box, which used to be a necessity up until now.
Fixed
Mounting
Style
M12 Connector Wiring & Tiered Construction
The stackable design and M12 connector quick
ector
disconnect (Cable Sold Separate) can drastically
n
reduce labor and time. Moreover, the
he
disconnection and reconnection of the body
when removing it to relocate a machine
hine
has become smoother.
Stackable Construction
on
High-contrast Visibility
With the adoption of an inner lens, the LED emits a more
efficient light. Moreso, the contrast is increased when the
Signal Tower lights up or flashes, with a distinguishable signal
color which remarkably improves visibility.
Remarkable display in ANY environment
The LS7 has passed various tests for water resistance, dust,
temperature, and variable vibration frequency tests, etc., so
that it can endure various environments.
All-plastic Bracket
Like the body, the smooth-shaped platform bracket
won't collect water or dust. Since no metal parts
like screws and shafts are exposed, worries of food
tampering can be put to rest in the food process lines.
