A platform that supports a progressive transition
from Traditional Analog Systems to High Definition IP solutions
1.0 Miles
Power
(Switch & Cameras)
(Wireless Access Point)
(Wireless Access Point)
PoE Switch
IP Camera
(PoE Enabled)
Analog
Camera (DVR)
IP Camera
(PoE Enabled)
Analog
Camera (DVR)
IP Camera
(PoE Enabled)
Power
(Antenna)
Analog
Camera (DVR)
Switch
DVR
3 IN 1
Monitor
Router / Hub
Other Devices
Internet
Modem
Remote PC
Yellow: Wireless Signal
Blue: Cat 5 or Cat 6
Black: Coaxial Cable
Red: Power
®
