Stand Alone Access Control
Locks & Interlocks
SKU# ACA10001
-Tubular lock / cam lock fit with 10001 tubular key.
-Depth 13.5mm door thickness 4.8mm.
-2,187 combinations.
SKU# ACVSM1228I
-Voltage Switch Module.
-(Input 12-28VDC, Output 12VDC/1A).
-Operating Temperature: -20 to 70oC.
SKU# ACA10004
SKU# ACA10002
-Tubular lock / cam lock fit with 10002 tubular key.
-Depth 16.5mm door thickness 8mm.
-78,125 combinations.
-Tubular lock / cam lock fit with 10004 tubular key.
-Depth 28.3mm door thickness 20.6mm.
-78,125 combinations.
SKU# ACIM2D
-Control module is required to synchronize the operation of
the two doors.
-When the first door opens, the second door shuts making
the opening of one door depend on the shutting of the other.
-Operating Temperature: -20 to 70oC, Overload 5A/24V.
