WATER-TO-WATER HEAT PUMPs
Heating
Heating
Options/accessories
• Medium and low temperature
applications
• Unit supplied in two assembled parts
• No disconnect switch, but with shortcircuit protection
• Single power connection point
• Evaporator/condenser pump electrical
power/control circuit options
• Service valve set
• Evaporator/condenser arrangement
with one pass
• Condenser insulation
• 21 bar evaporator and condenser
• Reversed evaporator water
connections
• JBus, BacNet and LON gateways
• Various condensing temperature
options
• Energy Management Module EMM
• Code compliance for Switzerland
and Australia
• Master/slave operation
• Touch Screen interface
• Low noise level (-3 dB(A) compared
to standard unit)
• Thermal compressor insulation
• Water connection kit for welded
or flanged evaporator/condenser
connections
30XWH
Features
• Twenty standard-efficiency sizes with nominal cooling capacities from 273 to
1732 kW and nominal heating capacities from 317 to 1969 kW and eleven
high-efficiency sizes with nominal cooling capacities from 509 to 1756 kW
and nominal heating capacities from 584 to 1989 kW.
• The premium solution for industrial and commercial applications that require
optimal performances and maximum quality.
• Two versions: 30XW for air conditioning and refrigeration applications (see
separate entry), and 30XWH for heating applications.
• Two efficiency classes: the standard-efficiency 30XWH offers an optimised
balance of technical and economical aspects and superior energy efficiency,
whilst the high-efficiency 30XWHP offers unequalled energy efficiency at
minimised operating cost.
• Twin-rotor screw compressors with high-efficiency motor and a variable
capacity valve for exact matching of the cooling capacity to the load.
• Use of R-134a refrigerant with zero ozone depletion potential.
• Pro-Dialog control system.
• Flooded mechanically cleanable heat exchangers.
• Exceptional full and part load energy efficiency.
• Economizer system with electronic expansion device for increased cooling
capacity (30XWHP).
• Simplified electrical connections.
• Units are run-tested before shipment and include a quick-test function for
fast commissioning.
• Leak-tight refrigerant circuit.
• Comprehensive endurance tests.
• Aquaforce offers multiple remote control, monitoring and diagnostic possibilities.
\\MAINMENU\STATUS
CAPB_T
DEM_LIM
SP
CTRL_PNT
EMSTOP
0 %
100 %
4.2 °C
-28.9 °C
dsable
Circuit B Total Capacity
START/STOP
ENTER
PRO-DIALOG+
Pro-Dialog+ operator interface
96
Touch-screen Pro-Dialog operator interface
