30XW-V Physical data 30XW-V 580 630 810 880 1150 1280 Air conditioning/cooling floor application as per EN14511-3 : 2013 Condition 1 kW 587 652 812 858 1140 1305 Cooling capacity EER kW/kW 5.44 5.31 5.25 5.07 5.45 5.50 Eurovent class, cooling A A A A A A ESEER kW/kW 7.80 7.60 8.04 7.76 7.79 7.59 Condition 2 kW 791 846 1023 970 1528 1688 Cooling capacity EER kW/kW 6.96 6.50 6.22 5.63 6.85 6.64 Eurovent class, cooling A A A A A A kg 3152 3190 4157 4161 7322 7398 Operating weight* Dimensions Length x depth x height mm 3059 x 1087 x 1743 3290 x 1237 x 1950 4730 x 1164 x 1997 Semi-hermetic 06T screw compressor, 60 r/s Compressor Quantity, circuit A/B 1/1/1/1/1/1 1/1 Touch Pilot, inverter-driven compressor. electronic expansion valve (EXV) Capacity control Minimum capacity % 20 20 20 20 10 10 R-134a Refrigerant* Multi-tube type flooded Evaporator Multi-tube type Condenser 1470 1570† 1710† 1461 5.38 A 7.30 1604 5.05 NA 7.15 1741 4.94 NA 6.85 1703 5.99 A 7574 2093 6.00 A 7770 2273 6.00 A 7808 4730 x 1255 x 2051 1/1 1/1 1/1 10 10 10 NOTE: For the conditions please refer to page 31. † These models are not Eurovent certified, as they are out of Eurovent certification program scope. * Weight shown is a guideline only. To find out the unit refrigerant charge, please refer to the unit nameplate. Electrical data 30XW-V Power circuit Nominal voltage Control circuit supply Start-up current* Maximum power factor Maximum power input, circuit A/B*** Eurovent current draw, circuit A/B** Maximum current draw (Un), circuit A/B*** 580 V-ph-Hz kW A A 630 810 880 400-3-50 ± 10% 24 V, via internal transformer Negligible (lower than maximum current drawn) 0.91-0.93 0.91-0.93 0.91-0.93 0.91-0.93 155/193/222/246/175/200/240/265/270/330/380/421/- 1150 1280 1470 1570 1710 0.91-0.93 155/155 175/175 270/270 0.91-0.93 193/193 200/200 330/330 0.91-0.93 222/193 240/200 380/330 0.91-0.93 222/222 240/240 380/380 0.91-0.93 246/246 265/265 421/421 * Instantaneous start-up current ** Eurovent unit operating conditions: evaporator entering/leaving water temperature 12°C/7°C, condenser entering/leaving water temperature 30°C/35°C. *** Values obtained at operation with maximum unit power input. Values given on the unit name plate. Operating range Condenser leaving water temperature, °C 55 50 45 40 35 30 25 20 15 0 5 10 15 20 Evaporator leaving water temperature, °C 63 From approximately 50% to full load Part-load limit approximately 50% Minimum load limit
