30HXC
Physical data
30HXC
080
090
100
110
120
130
Air conditioning application as per EN14511-3: 2013
kW
287
312
349
375
413
450
Nominal cooling capacity
EER
kW/kW
5.04
4.80
4.85
4.57
4.86
4.69
Eurovent class
B
B
B
C
B
B
ESEER
kW/kW
5.56
5.41
5.31
5.28
5.23
5.21
kg
2274
2279
2302
2343
2615
2617
Operating weight
Dimensions, standard unit
Depth
mm
2558
2558
2558
2565
3275
3275
Length
mm
980
980
980
980
980
980
Height
mm
1800
1800
1800
1850
1816
1816
R-134a
Refrigerant
06N semi-hermetic twin-screw compressor
Compressors
Quantity - Circuit A
1
1
1
1
1
1
Quantity - Circuit B
1
1
1
1
1
1
Capacity control
Pro-Dialog Plus control
No. of control steps
6
6
6
6
6
6
Shell and tube with internally finned copper tubes
Evaporator
Water connections
Victaulic
Inlet/outlet
in
4
4
4
5
5
5
Shell and tube with internally finned copper tubes
Condenser
Water connections
Victaulic
Inlet/outlet
in
5
5
5
5
5
5
NOTE: For the conditions, please refer to page 31.
140
155
175
190
200
230
260
285
310
345
375
510
4.72
B
5.17
2702
542
4.55
C
4.85
2712
599
4.68
B
5.03
3083
652
4.72
B
4.97
3179
701
4.74
B
5.08
3873
814
4.73
B
5.06
4602
899
4.45
C
5.01
4656
986
4.76
B
5.11
4776
1109
4.76
B
5.49
5477
1207
4.55
C
5.39
5553
1302
4.65
B
5.34
5721
3275
980
1816
3275
980
1816
3275
980
1940
3275
980
1940
3903
1015
1980
3924
1015
2060
3924
1015
2060
3924
1015
2060
4533
1015
2112
4533
1015
2112
4533
1015
2112
1
1
1
1
1
1
1
1
2
1
2
1
2
1
2
1
2
2
2
2
2
2
6
6
6
6
8
8
8
8
10
10
10
5
5
5
5
6
6
6
6
8
8
8
5
5
6
6
6
8
8
8
8
8
8
140
155
175
190
200
230
260
285
310
345
375
Not applicable to high condensing temperature units - please refer to electronic selection catalogue.
Electrical data
30HXC
080
090
100
110
120
130
Power circuit
Nominal power supply (Un)*
V-ph-Hz 400-3-50 ± 10%
Control circuit supply
The control circuit is supplied via the factory-installed transformer
Nominal current drawn*
A
101
115
127
143
149
168
190
207
226
234
255
294
337
354
399
448
477
Maximum starting current***
A
181
206
223
249
267
298
333
355
382
442
841
978
1027
1200
1129
1184
1373
Circuit A**
A
-
-
-
-
-
-
-
-
-
-
712
822
871
1028
844
871
1028
844
871
1028
Circuit B**
A
605
715
715
856
*
Standard Eurovent conditions: Evaporator entering/leaving water temperature 12°C and 7°C. Condenser entering/leaving water temperature 30°C/35°C.
** Maximum unit operating current at maximum unit power input.
*** Maximum instantaneous starting current (maximum operating current of the smallest compressor(s) + locked rotor current or reduced starting current of the largest compressor).
Operating range
58
Notes:
1. Evaporator and condenser ΔT = 5 K
2. For start-up at full load with a condenser water
entering temperature below 20°C, a three-way
valve must be used to maintain the correct
condensing temperature
3. Maximum condenser water leaving temperature
50°C (at full load)
A Standard unit operating at full load.
B Standard unit operating at reduced load.
C Units operating with head pressure control with
analogue water control valve. For transient
operating modes (start-up and part load) the
unit can operate down to a condenser entering
water temperature of 13°C.
Additional operating range for high condensing
temperature units and non-reversible heat
pumps.
Condenser water entering temperature, °C
50
B
45
35
30
A
25
20
C
15
13
4
5
10
13 15
20
Evaporator leaving water temperature, °C
59
