30XAV
Physical data
30XAV
Air conditioning application as per EN14511-3: 2013
Nominal cooling capacity*
EER*
ESEER*
Sound power level, standard unit
Sound power level, unit with option 279**
Sound power level, unit with options 257 and 279 **
Operating weight ***
Dimensions
Length
Width
Height
Compressor
Compressors / Circuits
Minimum capacity
Control
Refrigerant
Refrigerant charge***
Condenser
500
600
700
800
kW
kW/kW
kW/kW
dB(A)
dB(A)
dB(A)
kg
509
3.20
4.46
102
99
96
4901
611
3.20
4.55
103
100
97
5264
695
3.14
4.50
103
100
97
5865
819
3.33
4.74
103
100
97
6524
mm
mm
mm
6192
6192
7386
8380
2253
2253
2253
2253
2297
2297
2297
2297
Variable speed, inverter-driven screw compressor (06T, Carrier proprietary technology)
2/2
2/2
2/2
2/2
10
10
10
10
Touch Pilot, with 7'' touch screen
R134a
93
106
116
131
All aluminium micro-channel heat exchanger (MCHE)
kg
Fans
Quantity
Evaporator
IN
IM
L
%
RE
P
Y
AR
TA
DA
Variable speed, inverter-driven axial fans (Flying Bird 4, Carrier proprietary technology)
9
10
12
14
Flooded, shell-and-tube type
30XAV range will extend up to 1200 kW. Contact Carrier sales force for more details.
* Preliminary performance data given at evaporator entering/leaving water temperature 12/7°C, outside air temperature 35°C
** Option 279 = compressor enclosure. Option 257 = low sound option
*** Unit weight and refrigerant charge shown are guidelines only. To find out values, please refer to the unit nameplate.
NOTE:
• At time of printing this catalogue, units are not yet certified within the Eurovent LCP-HP program so data should be treated as preliminary
• Preliminary data is provided for the purposes of early design sizing and physical dimensioning
• Carrier, as an active particpant of Eurovent Certified Performance (ECP) programs, will submit data to the Eurovent Certita Certification (ECC) once development is finalized and products are available for market
launch
Operating range
30XAV Operating MAP (option 257)
30XAV Operating MAP Standard unit
50
40
40
30
Entering air temperature, °C
Outdoor air temperature, °C
50
20
10
0
-10
20
10
0
-10
-20
2
7
12
-20
17
2
Evaporator leaving water temperature, °C
°
7
12
Evaporator leaving water temperature, °C
MAP - PL (All Unit Sizes)
MAP - PL (30XAV0500 Only)
MAP - FL
30
MAP - PL (All Unit Sizes)
MAP - PL (30XAV0500 Only)
MAP - FL
Below 0°C air temperature the unit must either be equipped with the evaporator frost protection option (41A), or the water loop must be protected against frost by using a
frost protection solution (by the installer)
