30RB 017-033
Physical data
30RB
Air conditioning application as per EN14511-3: 2013
Condition 1
kW
Nominal cooling capacity
EER
kW/kW
Eurovent class
ESEER
kW/kW
Condition 2
kW
Nominal cooling capacity
EER
kW/kW
Operating weight*
Standard unit (with hydronic module)
kg
Standard unit (without hydronic module)
kg
Refrigerant*
Compressor
Control
Fans
Air flow
l/s
Evaporator
Condenser
Unit with hydronic module
Power input*
kW
Nominal operating current**
A
Dimensions
Length x depth x height
mm
NOTE: For the conditions, please refer to page 31.
*
017
021
026
033
16.4
3.04
B
3.46
21.4
3.11
A
3.47
27.3
3.08
B
3.44
33.3
3.28
A
3.62
22.7
3.80
29.5
3.86
38.6
4.01
45.8
4.11
189
208
255
280
173
193
237
262
R-410A
One hermetic scroll compressor
Pro-Dialog+
Two twin-speed axial fans, 3 blades
One twin-speed axial fan, 7 blades
2212
2212
3530
3530
Plate heat exchanger
Copper tubes and aluminium fins
One single-speed pump, screen filter, expansion tank, flow switch, pressure gauge, automatic air purge valve, safety valve
0.54
0.59
0.99
1.10
1.30
1.40
2.40
2.60
1136 x 584 x 1579
1136 x 584 x 1579
1002 x 824 x 1790
1002 x 824 x 1790
Weight shown is a guideline only. To find out the unit refrigerant charge, please refer to the unit nameplate.
Electrical data
30RB
017
021
026
033
Power circuit
Nominal power supply
V-ph-Hz
400-3-50 ± 10%
24 V via internal transformer
Control circuit supply
A
75
95
118
118
Maximum start-up current (Un)*
kW
7.8
9.1
11
13.8
Maximum operating power input**
A
8
12
16
17
Nominal unit operating current draw***
*
Maximum instantaneous start-up current (locked rotor current of the compressor).
**
Power input, compressors and fans, at the unit operating limits (saturated suction temperature 10°C, saturated condensing temperature 65°C) and nominal voltage of 400 V (data given on the unit nameplate).
*** Standardised Eurovent conditions: water heat exchanger entering/leaving water temperature 12°C/7°C, outside air temperature 35°C.
Operating range
53
48
Outside air temperature, °C
43
38
33
28
23
18
13
8
3
-2
-7
-12
-4
-2
0
2
4
6
8
10
12
14
16
18
20
22
24
Evaporator leaving water temperature, °C
Operating range with anti-freeze solution
and Pro-Dialog configuration.
37
