30AWH 004-015
Physical data
30AW
Air conditioning application as per EN14511-3: 2013
Nominal cooling capacity
EER
ESEER
Cooling floor application as per EN14511-3: 2013
Nominal cooling capacity
EER
Operating weight
Unit with hydronic module
Unit without hydronic module
Refrigerant
Compressor
Fans
Quantity/diameter
Dimensions
Length x depth x height

004

006

008

012

015

012-3Ph

015-3Ph

kW
kW/kW
kW/kW

3.3
3.02
4.36

4.7
3.00
4.51

5.8
2.98
4.15

10.2
2.96
4.22

13.0
2.95
4.31

10.2
3
4.4

13.0
2.91
4.31

kW
kW/kW

4.93
4.2

7.04
3.7

7.84
3.99

13.54
3.66

16.04
3.85

13.5
4.15

16
3.81

kg
kg

57
54
R-410

61
58
R-410A

69
66
R-410A

116
113
R-410A

116
113
R-410A

mm

1/495

1/495

1/495

2/495

2/495

mm

908 x 350 x 821

908 x 350 x 821

908 x 350 x 821

908 x 350 x 1363

908 x 350 x 1363

908 x 350 x 1363

908 x 350 x 1363

004
230-1-50
198-264
7.2
10
2.5

006
230-1-50
198-264
11
16
2.5

008
230-1-50
198-264
14
16
2.5

012
230-1-50
198-264
23
25
2.5

015
230-1-50
198-264
20
25
2.5

012-3Ph
400-3-50
376-424
16
20
2.5

015-3Ph
400-3-50
376-424
16
20
2.5

104
112
101
109
R-410A
R-410A
DC twin-rotary with PMV expansion valve
Propeller fans
2/495
2/495

NOTE: For the conditions, please refer to page 31.

Electrical data
30AW
Power supply
Voltage range
Full load current
Fuse rating
Main power cable section

V-ph-Hz
V
A
A
mm2

Operating range
Operation in cooling
20
18

Leaving water temperature, °C

Outlet water temperature [°
C]

30AWH 006
16
14

30AWH 004
12
10
8
6
4
2
0
-5

0

5

10

15

20

25

30

Outdoor air temperature [°
Outside air temperature, °C C]

35

35

40

45

50
