AQUASMART EVOLUTION
FEATURING THE NEW TOUCH PILOT SYSTEM MANAGER
Controls
Aquasmart
Description
• Aquasmart Evolution is a complete
hydronic heating, ventilating and air
conditioning (HVAC) system ideal for
residential and light commercial
applications from offices, commerce to
hotels and hospitals. It offers perfect
comfort for building occupants
whilst optimising economical
operation for applications up to
2500 m². Larger installations with
multiple systems can be managed and
integrated within a single Building
Management solution thanks to the
new BACnet option capability
(available as option in 2012).
• An Aquasmart system consists of up
to 128 terminal fan coil units, served
by up to two chillers or heat pumps
(master-slave), to supply cooling and/
or heating to occupied spaces and
fresh air handling units. The system
manager can fully integrate and
control up to eight Carrier fresh air
handling units* (39SQ). Each fresh air
plant can be associated with specific
terminal fan coils and/or zones for
optimum building use management
with occupancy, controlling and
minimising energy use.
• Individual schedules can be set up
and managed for each and all air
treatment plants. The Aquasmart
System Manager supplies building
information enabling dynamic and
precise control of the 39SQ’s nighttime free-cooling feature to further
reduce building energy consumption.
Features
• The Aquasmart Evolution system ensures significant energy savings combined
with optimised user comfort by managing building zoning, occupancy and
room temperatures in accordance with needs.
• Terminal fan coil units can be organised in up to 32 zones to optimise building
management by zone requirement and according to building design conditions.
• The Touch Pilot System Manager – the brain and building user interface – was
designed to facilitate use and allow rapid access to manage and configure
system operation to maximise energy savings at comfort conditions.
• System components are fitted with communicating controls allowing the
System Manager to communicate with and obtain feedback on user needs
and operation. Based on the system requirements the System Manager
coordinates the system heating and cooling modes for maximum comfort
and optimal energy consumption, respecting the comfort parameters and
occupancy schedules for the building zones.
• The Aquasmart system offers affordable building HVAC system management
featuring capabilities usually only available in more expensive solutions and
requiring additional building-by-building programming development.
* If air treatment unit is not supplied by Carrier, integration is
limited to control via a digital output for the main fresh-air
unit.
