19XR/XRV
Physical data
Nominal capacity, kW

Heat exchanger size

19XR/XRV
1000-5300

*
**

3
4
5
6
7
8
With two-pass nozzle-in-head water boxes.
Maximum height

Dimensions, mm
Length* - Standard
4230
4230
4230
4230
4919
4919

Average operating weight, kg
Length* - Extended
4754
4754
4754
4754
5525
5525

Width (excl. 19XRV)
1670
1880
2054
2124
2530
2530

Height**
2127
2294
2781
2879
3276
3343

8000
10204
12698
15420
17765
25712

19XR refrigeration cycle
Flasc chamber

Condenser water

Condenser

Float valve chamber

Condenser isolation valve (optional)
Transmission

Motor

Diffuser
Filter drier

Guide vane motor

Stator

Rotor
Orifice

Oil filter

Refrigerant liquid

Oil
pump

Guide
vanes
Impeller

Oil cooling

Compressor

Thermal expansion valve (TXV)

Back pressure orifice

Refrigerant vapour
Refrigerant
liquid/vapour

Chilled water

Cooler

Distribution pipe

Cooler isolation valve (optional)

145
