packageD ROOFTOP
HEAT PUMPS
Air treatment
48/50 UA/UH
Options/accessories
•
•
•
•
•
•
•
•
•
•
Electric heaters, various capacities*
Hot-water coils, various capacities*
Various coil protection options*
Gaz burner, various capacitie
Fresh-air sliding panel*
Manual outdoor air damper*
Economizer, thermostatic or enthalpy
control, with or without CO2 sensor
control*
Supply fan with various high static
pressure options with or without
soft starter*
Variable Air Volume supply fan*
Various filter options*
Stainless steel drain pan*
Energy recovery module*
Various return/exhaust air options*
Various temperature sensor options*
CCN/JBus, Lon or BACnet gateways*
Dirty filter detection*
Supply air flow detection*
Smoke detector*
Fire thermostat*
Duct connection fixing frame*
Various packaging options*
Vertical supply roof curb**
Vertical supply roof curb with
longitudinal adjustment**
Vertical supply roof curb with
transversal adjustment**
Horizontal supply roof curb**
Transition roof curb (French ERP)**
Remote user interface (Pro-Dialog+)**
* Option
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
** Accessory
Features
• Seven sizes with nominal cooling capacities from 44 to 109 kW and nominal
heating capacities from 44 to 112 kW.
• Cooling only or packaged reversible rooftop heat pumps, available with additional
heating options (hot-water coil or electric heaters).
• Versatile and efficient heat pumps, designed for outdoor installation.
• Self-contained, can be installed in commercial and industrial applications.
• Units use the ozone-friendly refrigerant R-410A that does not affect the ozone
layer.
• Components are specifically designed for R-410A refrigerant.
• Reduced size and weight make these units ideal for today’s lightweight building
structures.
• Cabinet made of powder-painted sheet metal.
• Compressors are hermetic scroll compressors and mounted on vibration isolators.
• Crankcase heaters are standard for all units.
• Low-noise shrouded axial Flying Bird fans, made of composite plastic material.
• Heat exchangers made of high-quality staggered copper tubing, mechanically
bonded into pre-coated corrugated aluminium fins.
• Leak-tight refrigerant circuits with brazed connections and reduced vibration levels.
Access to pressure transducers and temperature sensors without losing charge.
• Units are fully wired in accordance with EN standards.
• Simplified electrical connections.
• Reduced defrost cycle duration due to the new coil design and an auto-adaptive
control algorithm.
• High part load efficiencies and easy commissioning with Variable Air Volume supply
fan option.
\\MAINMENU\STATUS
CAPB_T
DEM_LIM
SP
CTRL_PNT
EMSTOP
0
100
4.2
-28.9
dsable
%
%
°C
°C
Circuit B Total Capacity
START/STOP
ENTER
PRO-DIALOG+
Pro-Dialog+ operator interface
140
