Room Fan Coil units
Air treatment
42N
Accessories
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Supporting feet
Supporting feet and cover panel
Return air grille for cabinet unit
Rear closing panel
Cabinet on concealed units,
Discharge air sleeve (concealed units
only)
Supporting brackets
A and B-type thermostats
Special installation kit
Cold draught prevention kit - all
two-pipe sizes
Automatic changeover switch
Air sensor with 15 m cable
Water sensor kit with 15 m cable
Infrared remote controller and
infrared remote receiver kit
ZUI1 or ZUI2 interface
SUI1 or SUI2 (with/without fan
speed selection)
Features
• Eleven sizes with two-pipe, two-pipe changeover or four-pipe coil; air flow range
35-422 l/s, cooling capacity range 0.8-6.4 kW, heating capacity range 1.1-9.5 kW.
• The 42N_S is available with a new-generation three- or five-speed AC motor.
The 42N_E is available with a variable-speed low energy consumption EC motor.
• Concealed or cabinet chilled-water fan coil system, designed for vertical and
horizontal installation in a room or above a false ceiling.
• Economical cooling and heating for hotels, commercial and residential applications.
• Cabinet version complete with control terminal.
• Combines aesthetic slim-line design with high installation flexibility.
• Two fan types, a tangential fan for ultra-low noise level and a centrifugal fan
for high air distribution system compatibility.
• Factory-mounted PTC electric heater with low and high capacity settings.
• Low hydraulic pressure drop with a val fR
