CASSETTE FAN COIL UNITS
Air treatment
42GW
Options/accessories
•
•
•
•
•
Two- or four-way valves
Fresh air inlet
Conditioned air to adjacent room kit
Electric heater
Auxiliary drain pan
Features
• Six sizes with integrated cooling and heating coils, two-pipe or two-pipe with
electric heater, and four-pipe applications. Air flow range 100-400l/s, cooling
capacity 1.6-8.7kW, heating capacity 2.2-15.5kW.
• The 42GW_AC is available with a new-generation three-speed AC motor. The
42GW_LEC is available with a variable-speed Low Energy Consumption EC motor.
• Designed for installation in false ceilings with an all-in-one air distribution grille.
• Reliable cooling and heating for offices, shops, restaurants, meeting rooms.
• Elegant air inlet grille, blends in with any room décor.
• Light and easy to install. The small chassis fits neatly with standard ceiling tiles.
• Four-way air distribution for individual comfort or localised control.
• New centrifugal fan and the fan/motor assembly ensure extra-quiet operation.
• Standard filter has a pleated surface that is 87% larger than in a conventional filter.
• Special diffuser design for rapid blending of supply and room air. Conditioned
air is directed along the ceiling. Return air enters the unit through a large grille.
• High-performance condensate drain pump for fast and quiet condensate removal.
• Easy maintenance with direct access from below to all main components.
Standard controls
Aquasmart New System Manager
Electronic thermostat
• Four versions, A, B, C and D, with potentiometer
• EC versio, three configurable discrete speeds via 0-10 V signal
• Automatic or manual three-speed selection
• Automatic or manual change-over
• Electric heat control
• Comfort/economy/frost protection modes
HDB controller
• Digital display or infra-red terminal
• Unit grouping capability
• Adjustable settings and parameters
• Timer and daily scheduling
NTC communicating controller
• Network communication
• Aquasmart Evolution system compatible
• IAQ and DCV management
• Motorised blinds & lighting control
104
