30XWHV
Physical data
30XWHV
Heating application - as per EN14511-3 : 2013
Condition 1
Heating capacity
COP
Eurovent class, heating
Condition 2
Heating capacity
COP
Eurovent class, heating
Operating weight*
Dimensions
Length x depth x height
Compressor
Quantity, circuit A/B
Capacity control
Minimum capacity
Refrigerant*
Evaporator
Condenser

580

630

810

880

1150

1280

1470†

1570†

1710†

kW
kW/kW

648
4.64
A

719
4.53
A

890
4.56
A

974
4.43
B

1261
4.62
A

1428
4.61
A

1594
4.55
N.A

1761
4.33
N.A

1932
4.16
N.A

kW
kW/kW

687
6.15
A
3152

767
5.98
A
3190

956
5.96
A
4157

1021
5.81
A
4161

1335
6.05
A
7322

1524
6.00
A
7398

1712
5.82
N.A
7574

1898
5.49
N.A
7770

2067
5.34
N.A
7808

kg
mm

%

3059 x 1087 x 1743
3290 x 1237 x 1950
4730 x 1164 x 1997
4730 x 1255 x 2051
Semi-hermetic 06T screw compressor, 60 r/s
1/1/1/1/1/1
1/1
1/1
1/1
Touch Pilot, inverter-driven compressor. electronic expansion valve (EXV)
20
20
20
20
10
10
10
10
R-134a
Flooded multi-tube type, maximum operating pressure 1000 kPa, 3/8” NPT drain and vent connections
Flooded multi-tube type, maximum operating pressure 1000 kPa, 3/8” NPT drain and vent connections

1/1
10

NOTE: For the conditions please refer to page 73.
