If FotoXStream for Macintosh is used for making remote layouts, it will be necessary set up Macintosh
to Windows volume mapping for Color Factory to be able to successfully read out the paths in the JRF
files. By clicking Add you may enter the Macintosh volume name and the corresponding Windows path
to the resources. (See the above screenshot for an example path.)
External XML formats
Where: Channel | Job Request Files | External XML formats tab
These options enable Color Factory to accept XML-based “job requests files” from other systems.
Enable Funkinform Crop Creation XML – Select this option to process Funkinform XML files.
To ignore color management options specified in the XML, select Ignore RGB Color Management
Commands in XML file and/or Ignore Grayscale Color Management Commands in XML file.
Enable CCI NewsDesk XML – Select this option to allow processing according to the CCI XML
format. Note that the image file and XML from CCI are archived together in a zip file, which means that
you must enable unpacking of zip files under the Input Options node (Miscellaneous tab) and remember
to select the Include Subfolders option on that tab.
Configuring automatic file routing
Where: Channel | Auto Routing
Using Auto Routing Color Factory can be configured to store files in subfolders within the output folder.
Routing may be based on a number of criteria, as you will see below.
Adding a routing entry (general procedure)
Click Add to bring up the routing method dialog where you may choose the type of routing you wish
to apply. As you will see, there are a number of methods to choose from, all of which will be described
below.
Choose the type of routing and a name describing the function of the routing and click OK. Then set
your preferences in the following dialog and click OK to save the settings.
All routing entries will be shown in the AutoRouting list, and you may change the order of the entries as
you like, so that multiple routing methods can be applied within the channel in any order you like.
