Conf ig ur in g Di amet er Cli ent Nod es an d Re lay Ag ent s
3869relayrelay
Configuring the Rf Client Application
The WebLogic SIP Server Rf client application enables SIP Servlets to issue offline charging
messages using the IMS Rf interface. To configure the Rf application, specify the class
com.bea.wcp.diameter.charging.RfApplication. The Rf application accepts the
following parameters:
z cdf.host specifies the host name of the Charging Data Function (CDF).
z cdf.realm specifies the realm of the CDF.
See Using the Diameter Rf Interface Application for Offline Charging in Developing
Applications with WebLogic SIP Server for more information about using the Rf application API
in deployed applications.
Configuring the Ro Client Application
The WebLogic SIP Server Ro client application enables SIP Servlets to issue online charging
messages using the IMS Ro interface. To configure the Rf application, specify the class
com.bea.wcp.diameter.charging.RoApplication. The Ro application accepts the
following parameters:
z
ocs.host specifies the host identity of the Online Charging Function (OCF). The OCF
you specify host must also be configured as the peer for the Diameter node on which the
Ro application is deployed.
4-16
Configuring Network Resources
